Labconco FlaskScrubber Vantage Series User Manual

Product Service 1-800-522-7658 41
C
C
H
H
A
A
P
P
T
T
E
E
R
R
6
6
M
M
O
O
D
D
I
I
F
F
Y
Y
I
I
N
N
G
G
Y
Y
O
O
U
U
R
R
W
W
A
A
S
S
H
H
E
E
R
R
The configuration of your washer may be changed to accommodate your needs.
For example, you may want to install pipet inserts, install an optional top rack, or
install an optional Cool Drain Water Kit. Spindle racks can be replaced with
racks without spindles for washing wide mouth glassware. Refer to Appendix A:
Glassware Washer Accessories for the accessories that are available for your
Glassware Washer.
Installing the Optional Upper Spindle Rack
The Upper Spindle Rack expands the capability of the FlaskScrubber by
providing 30 additional spindles for washing narrow-neck glassware. The rack
may be customized by removing spindles or by installing Multi-Pin Inserts which
hold beakers or other wide mouth glassware.
To install the optional Upper Spindle Rack:
Install the upper rails and the upper spindle rack. See the figure below.
1. Remove the acorn nuts and lockwashers from both upper sides using a 3/8"
wrench. There are 4 on each side.
