Lantronix UDS2100 Quick Start Guide

ASSIGN IP ADDRESS CONTINUED...
4. Select Assign a specific IP address to assign a static IP address to the
device,or select Obtain an IP address automatically to enable BOOTP, DHCP
or Auto IP on the device.Click Next.
6
WWW.LANTRONIX.COM
ASSIGN IP ADDRESS CONTINUED
5. Enter the IP address,
subnet mask, and
gateway for the device
in XXX.XXX.XXX.XXX
format. Click Next.
6. Click the Assign
button to finalize the
IP assignment.
7
Quick Start Guide
UDS2100
Figure 3. Assignment Method
Figure 4. IP Settings
Figure 5. Assignment

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
