LaserLiner CompactCross-Laser User Manual

CompactCross-Laser
17
Technical data
Self-levelling range
± 4°
Accuracy
± 0.35 mm / m
Operating range
15 m (depending on room illumination)
Operating range
with hand receiver
30 m
(depends on how the technology
affects the difference in brightness)
Laser wavelength 635 nm
Laser class
2 / < 1 mW
(EN 60825-1:2014/AC:2017)
Power supply
2 x 1.5V LR6 (AA)
Operating time
approx. 14 hours
Operating
conditions
-10°C ... 50°C, Max. humidity 80% rH,
no condensation, Max. working altitude
4000 m above sea level
Storage conditions -10°C ... 70°C, Max. humidity 80% rH
Radio module
operating data
IEEE 802.15.4. LE ≥ 4.x (Digital
Connection) interface; Frequency
band: ISM band 2400–2483.5 MHz,
40 channels;
Transmission power: max.
10 mW;
Bandwidth: 2 MHz; Bit rate:
1 Mbit/s; Modulation: GFSK/FHSS
Dimensions
75 x 88 x 58 mm
Weight
246 g (incl. batteries)
Subject to technical alterations. 21W29
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
This product is an electric device and must be
collected separately for disposal according to
the European Directive on waste electrical and
electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info/?an=AGO
Calibration
The meter needs to be calibrated and tested on a regular
basis to ensure it produces accurate measurement results.
We recommend carrying out calibration once a year.
EN
