Puridest Bi Distillation Apparatus model PD 8 D
12.2
PD 8 D
Exterior dimensions (W x D x H) 735 mm x 390 mm x 720 mm
Distillation capacity 8 l / h mono or bi distillate
Distillate quality Mono distillate
approx. 2.1 µS / cm at 25 °C
Bi distillate
approx. 1.6 µS / cm at 25 °C
in conformity with DAB, bacteria and pyrogen free, low
gas content.
The conductivity of the distilled water is directly related to the chemical composition of the raw water. Components of the raw water having the same or
a lower evaporation point than water may deteriorate the conductivity.
Cooling water required 198 l / h
Low water cut-off Electromechanical temperature limiter, with capillary tube
sensor.
Switch-off temperature 135 °C / -15 K
Water pressure min. / max. > 3 bar / 7 bar
> 43.5 psi / 101.5 psi
Electrical connection
Mains supply /
On-site fuse
220 V / 3 ~ / PE +/-10 %, 50 / 60 Hz, 11.5 kW
Mains connection cable for permanent connection to the
mains, on-site 3 x 35 A inert
or
400 V / 3 ~ / N / PE +/-10 %, 50 / 60 Hz, 11.5 kW
Mains connection cable for permanent connection to the
mains, on-site 3 x 20 A inert
Caution! Mains voltage deviations, even with the mentioned limits, influence the quantity of distillate produced.
Protection class / - type I / IP20
Surrounding conditions Use only inside buildings (not in potentially explosive
areas).
Height above MSL up to 2000 m MSL
Ambient temperature +10 °C to +40 °C
Humidity max. 80 % rel. humidity to 31 °C, decreasing to 40 % rel.
humidity at 40 °C
Net Weight 43.0 kg
Weight with water filling 68.4 kg
