Puridest Bi
Distillati
on Apparatus
25
/
32
15
List of spare parts
When orde
ring spare pa
rts, please always
st
ate type a
nd serial n
umber of the uni
t in question.
24
26
Table of Contents
Operating Instructions
1
Table of Contents
5
Using of the Bi Distillation Apparatus
7
Intended Use
7
Improper Use
7
Warranty
8
Before Initiation
8
Transport, Set-Up and Location of the Distillation Apparatus
8
Removing the Transport Protection of the Glass Condenser
9
Operating Voltage
9
Water Connections
10
Tap Water Inlet ①
10
Inlet Separate Water Supply ❷
10
Outlet Separate Water Supply ❹
10
Cooling Water Outlet ⑥
11
Drain Bi-Stage Boiler⑦
11
Drain Mono Stage Boiler ⑧
11
Initiation
11
Functional Description
12
Distillation Apparatus for Double Distillation
12
Bi Distillation Apparatus with Separate Water Supply
12
Degassing
12
Maintenance, Service and Trouble Shooting
13
Descaling
13
Sterilising
13
Water Shortage in Mono or Bi Stage
14
Pilot Lamp "Clean
14
Disposal of Old Units
15
Technical Data
16
Puridest Bi Distillation Apparatus Models PD 2 D, PD 4 D
16
Puridest Bi Distillation Apparatus Model PD 8 D
17
Circuit Diagram
18
Pd 2 D
18
PD 4 D - Version 220 V / 3
19
PD 4 D - Version 400 V / 3
19
PD 8 D - Version 220 V / 3
20
PD 8 D - Version 400 V / 3
20
Connection to the Mains Supply
21
Connection to the Mains Supply (Examples)
22
PD 2 D for 230 V
22
PD 4 D and PD 8 D for 220 V / 3 ~ at Mains Supply 230 V / 3 ~ / PE 50 / 60 Hz
23
PD 4 D and PD 8 D for 400 V / 3 ~ at Mains Supply 400 V / 3 ~ / N / PE 50 / 60Hz
24
List of Spare Parts
25
Accessories and Options
27
