LawnMaster NPTGSP2617A User Manual

41
PARTS LIST
Replacement parts highlighted in grey are available for after sales purchase. Replacement of repair or
LQWHUQDOSDUWVVKRXOGRQO\EHGRQHE\DTXDOL¿HGVHUYLFHSURIUVVLRQDO3OHDVHFRQWDFW\RXUDXWKRUL]HG
service dealer or Customer Service at 886-384-8432.
NPTGSP2617A MANUAL PARTS LIST
Key Number Part Number Description Quantity
1
321001101 Cleva 26cc 2-Cycle Engine 1
2 321001102 Throttle-body & Starter Set 1
2.1 321001103 Throttle-body Set 1
2.2 321001104 Starter Set 1
2.2.2 321001106 Starter Switch Assembly 1
2.2.3 321001107 Stop Switch Set 1
2.2.4 321001108 PCB Assembly 1
3 321001109 Handle Spacer 2
4 141004102 Cable Clamp 2
5 321001111 Clutch Assembly 1
5.1 321005103 Screw 4
6 321001113 Wire Lock 1
7 321001114 7.2V Lithium-Ion Battery 1
8 321005103 Aluminum Upper Trimmer Shaft 1
9 321001116 Assist Handle Assembly 1
9.1 321001117 Assist Handle 1
9.2 321001118 Handle Clasp 1
9.3 321001119 %DOO-RLQW 1
9.4 321001120 Ball Socket 1
10 321005103 Shaft Connection Sleeve 1
11 321005103 Aluminum Lower Trimmer Shaft 1
12 321005106 Debris Guard Bracket 1
13 321001121 Gear Box 1
13.1 321005107 Screw 1
13.2 321001112 Bolt 1
13.3 321001122 Bolt 1
14 321001124 Cover Plate 1
15 321001125 Debris Guard 1
16 RR0100 Rapid Reload Head Assembly 1
16.1 321001129 Rapid Reload Spool Spring 1
17 321001127 Charger 1
18 221003102 Shoulder Strap (Available Separately) 1
19 321001128 Shoulder Strap Clasp (Available Separately) 1
20 321001114 M5 Hexagon Socket Wrench 1
21 321001114 M6 Hexagon Socket Wrench 1
22 321001114 Open End Wrench 1
23 321005103 Socket Wrench 1
