PARTS LIST 26CC 2-CYCLE ENGINE
26CC 2-CYCLE ENGINE PART LIST
Key Number Part Number Description Quantity
1
321001130 Spark Plug Cover 1
2 321001131 Nut 1
3 321001132 Upper Engine Cover 1
4 321001133 Logo 1
5 321001134 $LU'HÀHFWRU 1
6 321001135 Cylinder Assembly 1
7 321001136 0XIÀHU&RYHU 1
8 321001137 0XIÀHU 1
9 321001138 Insulation Sheet 1
10 321001139 Spark Plug 1
11 321001140 Crankcase Assembly 1
12 321001141 Ignition Coil Assembly 1
13 321001142 Stop Switch Cables 1
14 321001143 Pawl Assembly 1
15 321001144 Electric Starter Assembly 1
16 321001145 Carburetor Mount Assembly 1
17 321001146 Carburetor (with one sheet) 1
18 321001147 Air Filter Base 1
19 321001148 Air Filter 1
20 321001149 Air Filter Cover 1
21 321001150 Rotary Knob 1
22 321001151 Choke Lever 1
23 321001152 Fuel Cap Assembly 1
24 321001153 Fuel Tank Assembly 1
25 321001154 Rubber Pad 1
26 321001155 Fuel Tank Bracket 1
27 321001156 Lower Engine Cover 1
28 321001157 Crankshaft Piston Shank 1
29 321004138 Flywheel Cover Assembly 1
30 321001159 Flywheel Assembly 1
31 321001160 Screw 5
32 321001161 Self-Tapping Screw 2
33 321001162 Self-Tapping Screw 1
34 321001163 Screw 2
35 321001164 Rubber Plug 1
36 321001165 Nut 2
37 321001166 Washer 2
38 321001210 Screw 1
Replacement parts highlighted in grey are available for after sales purchase. Replacement of repair or
LQWHUQDOSDUWVVKRXOGRQO\EHGRQHE\DTXDOL¿HGVHUYLFHSURIUVVLRQDO3OHDVHFRQWDFW\RXUDXWKRUL]HG
service dealer or Customer Service at 886-384-8432.
To Next Page
