Lennox 14HPX-036-230-17 User Manual

Page 5
14HPX SERIES
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14HPX-030-230-01
1.0 30 17.2 12.9 64.0 1/5 825 1.1 1.4
2.0, 3.0,
4.0 & 5.0
30 17.0 13.1 64.0 1/10 1075 .70 1.3
14HPX-030-230-10 1.0 30 17.0 13.1 64.0 1/10 1075 .70 1.3
14HPX-030-230-11 1.0 30 17.0 13.1 64.0 1/10 1075 .70 1.3
14HPX-030-230-13 1.0 30 17.0 13.1 64.0 1/10 1075 .70 1.3
14HPX-030-230-14 1.0 30 17.0 13.1 64.0 1/10 1075 .70 1.3
14HPX-030-230-17 1.0 25 17.1 12.8 64.0 1/6 825 1.1 1.9
14HPX-030-230-18 1.0 25 17.1 12.8 64.0 1/6 825 1.1 1.9
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14HPX-036-230-01
1.0, 2.0,
3.0, 4.0 &
5.0
30 19.4 14.1 77.0 1/3 825 1.8 2.9
14HPX-036-230-10 1.0 30 19.4 14.1 77.0 1/3 825 1.8 2.9
14HPX-036-230-11 1.0 30 19.4 14.1 77.0 1/3 825 1.8 2.9
14HPX-036-230-12 1.0 30 19.4 14.1 77.0 1/3 825 1.8 2.9
14HPX-036-230-17 1.0 & 2.0 30 18.7 14.08 77.0 1/6 825 1.1 1.87
14HPX-036-230-18
1.0 30 18.7 14.08 77.0 1/6 825 1.1 1.87
2.0 30 18.7 14.1 77.0 1/6 825 1.1 1.87
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
14HPX-042-230-01
1.0 40 23.9 17.69 07.0 1/3 825 1.8 2.9
2.0 & 3.0 40 24.2 17.94 112.0 1/3 825 1.8 2.9
14HPX-042-230-10 1.0 40 24.2 17.94 112.0 1/3 825 1.8 2.9
14HPX-042-230-11 1.0 40 24.2 17.94 112.0 1/3 825 1.8 2.9
14HPX-042-230-12 1.0 40 24.2 17.94 112.0 1/3 825 1.8 2.9
14HPX-042-230-17
1.0, 2.0,
3.0 & 4.0
40 24.2 17.92 112.0 1/3 825 1.8 2.9
14HPX-042-230-18
1.0 40 24.2 17.92 112.0 1/3 825 1.8 2.9
2.0 40 24.2 18.0 112.0 1/3 825 1.8 2.9
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
