Figure 15
Three Phase Wiring Diagram P/N 48437-001
OUTDOOR
FAN
OUTDOOR FAN
CAPACITOR
PURPLE
BLACK
ORANGE
BLACK
BLACK
BLACK
RED
COMPRESSOR
CRANKCASE HEATER
COMPRESSOR
CONTACTOR
OUTDOOR FAN
RELAY
25
7
BLACK
T3
T2
T1
L3
L2
L1
DEFROST
CONTROL
BLACK
THERMOST
CR
W1
O
Y1
FAN
O-OUT
LO-PS
DF
Y1 OUT
COMMON
W1
C
L
R
O
Y1
2
2
HI-PS
BLUE
L1
L2
L3
208-230/60/3
1
GROUND
REVERSING
VALVE
S40
BLACK
GROUND
LUG
THERMOSTAT
C
R
W1
O
Y1
FAN
O-OUT
LO-PS
DF
Y1 OUT
COMMON
W1
C
L
R
O
Y1
2
HI-PS
CMC1
2
L1
S6
K1
208-230/60/3
L1
L2
L3
1
K1-1
BLACK
BLACK
BLACK
ORANGE
RED
C1
2
7
5
BLACK
BLUE
K10-1
B4
PURPLE
B1
EQUIPMENT
GROUND
HR1
S40
LO-PS
S87
LOW PRESSURE
SWITCH
S4
HIGH PRESSURE
SWITCH
HI-PS
WARNING--
ELECTRIC SHOCK HAZARD, CAN CAUSE INJURY OR DEATH. UNIT MUST
BE GROUNDED IN ACCORDANCE WITH NATIONAL AND LOCAL CODES.
LINE VOLTAGE FACTORY INSTALLED
LINE VOLTAGE FIELD INSTALLED
24 VOLT FACTORY INSTALLED
CLASS II VOLTAGE FIELD INSTALLED
1
FOR USE WITH COPPER CONDUCTORS ONLY. REFER TO UNIT
RATING PLATE FOR MINIMUM CIRCUIT AMPACITY AND MAXIMUM
OVERCURRENT PROTECTION SIZE.
2
CONNECTION MUST BE JUMPERED WHEN OPTIONAL SWITCH IS
NOT USED.
NOTE:
DO NOT CONNECT C (COMMON) CONNECTION BETWEEN THE INDOOR
UNIT AND THERMOSTAT EXCEPT WHEN REQUIRED BY THE INDOOR
THERMOSTAT. REFER TO THERMOSTAT INSTALLATION INSTRUCTIONS.
C (COMMON) CONNECTION BETWEEN INDOOR UNIT AND OUTDOOR
UNIT REQUIRED FOR PROPER OPERATION.
DESCRIPTION
KEY COMPONENT
B1 COMPRESSOR
B4
MOTOR - OUTDOOR FAN
C1 CAPACITOR - OUTDOOR FAN
HR1 HEATER - COMPRESSOR
K1-1 CONTACTOR - COMPRESSOR
S4 SWITCH - HIGH PRESSURE
S6 SWITCH - DEFROST
S40 THERMOSTAT - CRANKCASE
CMC1 CONTROL-DEFROST
S87 SWITCH - LOW PRESSURE
K10-1 RELAY - OUTDOOR FAN
L1 VALVE - REVERSING
