BALTIC-IOM-0412-E / Service manual
eDrive™ VENTILATION
eDrive™ mounting
eDrive™ assembly is designed to have no adjustment to be made inside the machine
In case of vertical misalignment one could use metallic washer located under the motor to adjust height
eDrive™ airfl ow reading
eDrive is controling the airfl ow within the operating range of each kit.
Airfl ow rate calculation inputs are rpm and power absorbed output read on the inverter variable bus.
The airfl ow rate calculation formula is calibrated according lab tests.
eDrive™ coupling dimensions
Coupling
Machine
size
Motor size
kW
Motor shaft
diameter
mm
Fan shaft
diameter
mm
Coupling
reference
Coupling type
PP
Motor moteur
bushing
ref
Fan taper
Ref
C box 2 x Taper lock bushing
C box 2 x Taper lock bushing
C box 2 x Taper lock bushing
C box 2 x Taper lock bushing
C box 2 x Taper lock bushing
D box 1 Taper lock bushing + D30
D box 1 Taper lock bushing + D30
D box 1 Taper lock bushing + D30
D&E box 5,5 to 7,5 1 Taper lock bushing + D38
E box 9 to 11 2 x Taper lock bushing
Max radial misalignment 3mm Vibration absorbtionMax angular misalignment 4° Max axial range 8 mm
