GENERAL DATA
BCK = Cooling only rooftop BHK = Heat pump rooftop BGK = Cooling only with gas fired heatingBDK = Heat pump rooftop with gas fired heating
(1) All data are at Eurovent condition at 400V/3Ph/50Hz+N.Gross cooling capacity with 35°C DB outdoor, 27°C indoor. Net heating capacity with 7°C DB outdoor, 20° C indoor.
(2)Gross COP =
Gross capacity / unit power input (compressor + con. fan + supply fan + control) (3) Net COP cooling = (Gross cooling capacity - fan motor heat) / unit power input (compressor + con. fan + supply fan +
control) (4)Net COP heating = (Gross heating capacity + fan motor heat) / unit power input (compressor + con. fan + supply fan + contol).
Table 3.2 SIZE 040 045 050
Performance
Nominal Airflow m3/h
Cooling BCK-BGK
Gross Cooling capacity (1) KW
Power input BCK kW
Power Input BGK kW
Full load amps A
Direct start up amps ratio Id / Ia -
COP gross BCK (2) -
COP net global BCK (3) -
COP net global BGK (3) -
Cooling BHK-BDK
Gross Cooling capacity (1) KW
Power input BHK kW
Power Input BDK kW
COP gross BHK (2) -
COP net global BHK (3) -
COP net global BDK (3) -
Heating BHK-BDK
Net heating capacity (1) kW
Power input BHK kW
Power input BDK kW
COP gross BHK (3) -
COP net global BHK (4) -
COP net global BDK (4) -
Heating - gaz fired
Heating capacity kW S / H
Input (small heat / high heat) kW S / H
Thermal efficiency % H
Refrigeration circuit
Nb of Circuits / Compressor type nb / type
Expansion nb / type
Refrigerant charge per circuit Clim / PAC kg
Coils
Indoor Coil :
Face area / nb of rows / Fin per inch m2 / nb / FPI
Outdoor Coil : Face area / nb of rows / Fin per inch m2 / nb / FPI
Ventilation data
Nominal Airflow m3/h
Minimum Airflow m3/h
Maximum Airflow m3/h
External static pressure nom / max Pa
Indoor fan (Centrifugal fan BCK/BHK)
Number / Drive type type
Number of motor nb
Mechanical Power (1) kW
Rotation speed RPM
Indoor fan (Centrifugal fan BGK/BDK S)
Number / Drive type type
Number of motor nb
Mechanical Power gas -S (1) kW
Rotation speed RPM
Outdoor fan (axial)
Number nb
Nominal Airflow m3/h
Motor power kW
Rotation speed RPM
Filter (furnished standard)
Efficiency / filter class / Eurovent type
Nb of filter nb
Filter size mm x mm
Dimension
Length (STD / GAZ) footprint without fresh air hood mm
Height mm
Width footprint without fresh air hood mm
Weight standard unit BCK kg
Weight gas unit BGK kg S
kg H
Acoustic at 100 Pa
Outside sound power on standard unit (1) dB(A)
Indoor blower outlet sound power on standard unit (1) dB(A)
Outside sound power on GAS unit (1) dB(A)
Indoor blower outlet sound power on GAS unit (1) dB(A)
Construction
Casing material
Min Casing thickness cm
Painting type/RAL
Insulation Class type
Cooling mode operating limits
Max. Outdoor temp. at Indoor 27°C DB / 19°C WB °C
Min. Outdoor temp. at Indoor 20°C DB °C
Max. entering Indoor coil temp. at Outdoor 40°C DB °C
Min. entering Indoor coil temp. at Outdoor 35°C DB °C
Heat pump mode operating limits
Min. Outdoor temp. at Indoor 20°C DB °C
Min. entering Indoor coil temp. at Outdoor 7°C DB °C
7200 8100 9000
40,2 44,2 47,7
16,7 19,2 22,1
17,4 20,2 23,3
40,4 44,0 48,1
3,1 3,4 3,2
2,4 2,3 2,2
2,3 2,2 2,1
2,2 2,1 1,9
39,7 43,7 47,3
16,7 19,2 22,1
17,4 20,2 23,2
2,4 2,3 2,1
2,3 2,2 2,0
2,2 2,1 1,9
38,8 42,7 47,3
14,4 16,2 18,3
15,1 17,2 19,4
2,6 2,5 2,5
2,7 2,6 2,6
2,6 2,5 2,4
30,7 / 55,8 30,7 / 55,8 30,7 / 55,8
33 / 60 33 / 60 33 / 60
93 93 93
2 / ZR90 Scroll 2 / ZR90 + ZR11 Scroll 2 / ZR11 Scroll
2 / TXV 2 / TXV 2 / TXV
5,5 5,5 5,7
1.25 / 3 / 14 1.25 / 3 / 14 1.25 / 3 / 14
2.2 / 2 / 16 2.2 / 2 / 16 2.2 / 2 / 16
7200 8100 9000
5800 6500 7200
8600 9700 10800
100 / 500 100 / 500 100 / 500
1 / AT 15-15 S 1 / AT 15-15 S 1 / AT 15-15 S
111
1,10 1,50 2,20
667 722 762
1 / AT 15-15 S 1 / AT 15-15 S 1 / AT 15-15 S
111
1,50 2,20 3,00
784 854 928
222
14350 14350 14350
1,1 1,1 1,1
1320 1320 1320
80-85 % / G3 80-85 % / G3 80-85 % / G3
444
497 x 624 x 45 497 x 624 x 45 497 x 624 x 45
1850 1850 1850
1220 1220 1220
2200 2200 2200
626 630 638
709 718 723
730 739 744
81,2 81,4 81,8
75,8 78,2 80,4
81,3 81,7 82,2
78,7 81,3 83,7
Aluzinc Aluzinc Aluzinc
0,10 0,10 0,10
polyester / 9002 polyester / 9002 polyester / 9002
M0 M0 M0
45 43 42
13 10 10
35 35 35
20 20 20
-9 -8 -7
888
