CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a safe
installation:
Side wall: 17” (324 mm) measured from the fireplace side.
Ceiling: 6’ 8” (2,032 mm) measured from the base of the fireplace.
Fireplace enclosure:
Bottom: 0”
Side: 0” to spacer
Back: 0” to spacer
Top: Do not fill the space above the fireplace with any material
(Except the wood framing. See Page 10, Figure 9).
Chimney: 2” (50 mm)
Mantel: 45” (1143 mm) measured from the base of the fireplace.
Brentwood™ Replacement Parts
Description Cat./Part No.
Baffle refractory (2 pieces) PR-ISO2205
Back refractory PR-SR2203
Right side refractory PR-SR2204D
Left side refractory PR-SR2204G
Bottom refractory PR-SR2201
Front refractory, right side - ash lip PR-SR2202D
Front refractory, left side - ash lip PR-SR2202G
Door handle PR-SR2325
Ceramic glass panel PR-SR2222-1
Secondary air tube PR-SR2271
Cast-iron log retainer supports - grate (2) PR-SR2324
Cast iron log retainer bar PR-SR2323
Touch-up paint, aerosol, black metallic SBMB6309 H8159
Louvers, upper and lower (1) PR-SR2218-1
Snap disc, blower VTU
Bracket, secondary air tube PR-SR2214
Hinge assembly, fireplace and door PR-SR2395UL
Door handle rod and mechanism PR-SR2118
Door handle and brass cap PR-SR2325
Door handle brass cap POIGNE002
Gasket, door, 73” (5/8” dia.) PR-SR1823G
Gasket, glass, 69” (5/16” dia.) PR-SR1823H
Blower 250 CFM for central forced air kit, BISZY BISZY
Blower variable speed control with decorative wall plate
for (BISZY), VRUW
VRUW
Thermo-disk, on/off blower control (for BISZY), VTU VTU
Blower to flexible pipe adaptor, BISAVF BISAVF
Backdraft damper, BISBD BISBD
Fireplace to Flex adaptor and 2 clamps, BISAF BISAF
REPLACEMENT PARTS LIST
SPECIFICATIONS
Cat. No. Model
H4825 Brentwood SP
Product Reference Information
Weight 385 lbs
Height 36”
Width 36”
Depth 24-1/2”
Firebox W x H x D - measured in front 22” x 11-3/4” x 12”
Chimney weight ASHT (6” dia) 6.25 lb per linear foot
Chimney weight AC (6” dia) 3.25 lb per linear foot
Chimney weight S2100+ (6” dia) 10.8 lb per linear foot
Contact an IHP dealer to obtain any of these parts. Never use substitute
materials not approved by IHP. Use of non-approved parts can result
in poor performance and safety hazards.
23
