506230−01 05/09
Page 14
Humidification
INSTALLER SETTINGS
Humidification (adding moisture to air) is provided only
when the thermostat is in heat mode. The humidification
signal (H terminal) to the humidifier (off when the thermo-
stat is in the COOL mode) controls humidification. When
the thermostat is powered, the H terminal is normally inac-
tive (open circuit) in any mode (HEAT, COOL, OFF). When
a humidification demand is present, H terminal and G ter-
minal are energized (24V).
HUMIDITY SETTINGdefault OFF. Installer settings
must be turned on before the user will have control
over the humidity. The mode selected determines how
the user can adjust the relative humidity (RH). The installer
settings include BASIC, PRECISION, DEWPOINT, and
OFF.
BASIC & PRECISIONthese thermostat modes allow
the user to control the relative humidity (RH) between 15
and 45%. The following conditions must be met for either
mode to operate:
S humidification mode has been enabled, and
S the unit is in HEAT mode, and
S humidification demand exists (24V present at H), and
Additionally, the BASIC mode requires:
S heat demand exists (Y energized for heat pump heat-
ing, or W energized for gas heat [W may be energized
with G de−energized]).
Scroll to HUMIDITY SETTINGS; press ENTER. Press the
box below HUMIDIFY.
HUMIDITY MODE
HUMIDIFY DEHUMIDIFY
| |
Use up/down arrows to select BASIC or PRECISION;
press ENTER.
HUM MODE SETTING
DEF(OFF) PRECISION
Default setting is 45% RH. Use up/down arrows to define
what NEW SETPOINT IS (between 15 to 45%); then press
SAVE.
HUM SETPOINT
DEFAULT (45%) 4O%
DEWPOINTDew point adjustment mode will change the
humidification setpoint based on the outdoor temperature
and a user−defined dew point adjustment setting.
NOTE − In dew point adjustment mode, the humidification
setpoint has no effect whatsoever on unit operation. Only
the user−defined dew point adjustment setting affects op-
eration per the following formula:
RH
setpoint
=
Outdoor Temp (ºF)
2
+ 25 +
RH
user
dew
point
adjustment
Where:
RH
user
dew
point
adjustment
cannot exceed +/−15% and
RH
setpoint
minimum is 15% and cannot exceed 45%.
Scroll to HUMIDITY SETTINGS; press ENTER.
HUMIDITY MODE
HUMIDIFY DEHUMIDIFY
| |
Press the box below HUMIDIFY. Use up/down arrows to
select DEWPOINT; press ENTER.
HUM MODE SETTING
DEF(OFF) DEWPOINT
Use up/down arrows to select new DEW POINT ADJ set-
point (between +15 to −15%); then press SAVE.
DEW POINT ADJ
DEFAULT (O%) −5%
NOTE − Dew point adj available only when outdoor sensor
is attached.
USER SETTINGS
BASIC & PRECISIONif set up by the installer settings
for BASIC or PRECISION, this adjustment controls the rel-
ative humidity (RH) between 15 and 45%.
Scroll to HUMIDITY SETTINGS; press ENTER. Press the
box below HUMIDIFY.
HUMIDITY MODE
HUMIDIFY DEHUMIDIFY
| |
Use up/down arrows to change the humidity setpoint (be-
tween 15 and 45%); press SAVE.
HUM SETPOINT
DEFAULT (45%) 4O%
DEWPOINTif set up by the installer settings for DEW-
POINT, this adjustment (only when in heating mode) will
change the humidification setpoint based on the outdoor
temperature and a user−defined dew point adjustment set-
ting. When humidifying, if condensation forms on the win-
dows, the dew point should be adjusted in the range of −15
to −5%; if the home feels dry, set dew point upward in the
range of +5 to +15%.
Scroll to HUMIDITY SETTINGS; press ENTER. Press the
box below HUMIDIFY.
HUMIDITY MODE
HUMIDIFY DEHUMIDIFY
| |
Use up/down arrows to change the dew point (between
+15 and −15%); press SAVE.
DEW POINT ADJ
DEFAULT (O%) −5%
NOTE − Dew point adj available only when outdoor sensor
is attached.
OFFif OFF selected in installer settings for both humidify
and dehumidify, this message appears when HUMIDITY
SETTING is pressed:
HUMIDITY MODES OFF
If OFF is selected by the installer settings for HUMIDIFY
but DEHUMIDIFY is on, the dehumidification menu ap-
pears (this setpoint adjust has NO effect on humidifica-
tion):
DEHUM SETPOINT
DEFAULT (5O%) 45%
