XC16 - 2 to 5 Ton Air Conditioner / Page 8
*tXV SUBSTITUTIONS
Indoor Coils/Air Handlers with factory installed expansion
valves that require eld replacement
Model No.
Indoor Coil or Air
Handler
Order No.
XC16-024 CBX26UH-024 37L51
XC16-036 CX34-42 37L51
XC16-036 CX34-43 37L51
XC16-036 CX34-44/48 37L51
XC16-036 CX34-49 37L51
XC16-036 CBX26UH-030 37L51
XC16-036 CBX27UH-072 37L51
XC16-036 CBX32M-042 37L51
XC16-036 CBX32MV-024/030 37L51
XC16-036 CBX32MV-048 37L51
XC16-036 CBX40UHV-030 37L51
XC16-036 CBX40UHV-042 37L51
XC16-036 CBX40UHV-048 37L51
XC16-048 CX34-44/48 91M02
XC16-048 CBX26UH-042 91M02
* Factory installed expansion valve on the indoor coil or air handler shown must
be replaced with the expansion valve listed (ordered separately).
TXV USAGE
Model No. Order No.
XC16-024 37L51
XC16-036 37L51
XC16-048 91M02
XC16-060 91M02
CX34 upow coils and all Lennox air handlers (except CB26UH “R”) are
shipped with a factory installed TXV. In most cases, no change out of the valve
is needed.
If a change out is required it will be listed in the “TXV SUBSTITUTIONS” table.
The correct TXV must be ordered and eld installed. C33 coils and all horizontal
and downow coils are shipped without a TXV. The TXV must be ordered and
eld installed.
MOST POPULAR MATCHES
Outdoor Unit
Model No.
Indoor Unit
Model No
XC16-024 CX34-36B with SL280UH090V36B
XC16-036 CX34-43C with SL280UH090V60C
XC16-048 CX34-62C with SL280UH090V60C
XC16-060 CX34-62C with SL280UH090V60C
