AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-024-230 TXV 25,200 14.20 11.70 CH23-41 3068768
XC16-024-230 TXV 25,400 16.50 13.00 CH33-19 SL280UH070V36A 3932948
XC16-024-230 TXV 25,400 16.50 13.00 CH33-19 SL280UH070XV36A 4037910
XC16-024-230 TXV 24,800 14.00 11.50 CH33-19 3068769
XC16-024-230 TXV 25,200 16.20 12.70 CH33-24/30 SL280UH070V36A 3932949
XC16-024-230 TXV 25,200 16.20 12.70 CH33-24/30 SL280UH070XV36A 4037911
XC16-024-230 TXV 24,600 14.00 11.50 CH33-24/30 3068843
XC16-024-230 TXV 25,800 16.70 13.00 CH33-25 SL280UH070V36A 3932950
XC16-024-230 TXV 25,800 16.70 13.00 CH33-25 SL280UH070XV36A 4037912
XC16-024-230 TXV 25,600 16.00 13.20 CH33-25 SL280UH090V36B 3932951
XC16-024-230 TXV 25,600 16.00 13.00 CH33-25 SL280UH090V48B 4249273
XC16-024-230 TXV 25,800 16.20 13.20 CH33-25 SLP98UH070V36B 4020625
XC16-024-230 TXV 25,400 14.50 11.70 CH33-25A 3068772
XC16-024-230 TXV 25,800 16.50 13.00 CH33-25B G61MPV-36B-045 3068821
XC16-024-230 TXV 25,800 16.50 13.00 CH33-25B G61MPV-36B-070 3068822
XC16-024-230 TXV 26,000 16.50 13.00 CH33-25B G61MPV-36B-071 3068824
XC16-024-230 TXV 25,200 14.20 11.70 CH33-25B 3068773
XC16-024-230 TXV 26,400 17.00 13.20 CH33-31 SL280UH070V36A 3932952
XC16-024-230 TXV 26,400 17.00 13.20 CH33-31 SL280UH070XV36A 4037913
XC16-024-230 TXV 26,200 16.50 13.50 CH33-31 SL280UH090V36B 3932953
XC16-024-230 TXV 26,200 16.50 13.20 CH33-31 SL280UH090V48B 4249274
XC16-024-230 TXV 26,400 16.70 13.50 CH33-31 SLP98UH070V36B 4020626
XC16-024-230 TXV 25,800 14.70 12.00 CH33-31A 3068774
XC16-024-230 TXV 26,400 16.70 13.20 CH33-31B G61MPV-36B-045 3068827
XC16-024-230 TXV 26,400 16.70 13.20 CH33-31B G61MPV-36B-070 3068828
XC16-024-230 TXV 26,600 17.00 13.20 CH33-31B G61MPV-36B-071 3068830
XC16-024-230 TXV 25,800 14.50 12.00 CH33-31B 3068775
XC16-024-230 TXV 25,600 16.50 13.00 CH33-36 SL280UH070V36A 3932954
XC16-024-230 TXV 25,600 16.50 13.00 CH33-36 SL280UH070XV36A 4037914
XC16-024-230 TXV 25,600 16.00 13.20 CH33-36 SL280UH090V36B 3932955
XC16-024-230 TXV 25,600 16.20 13.20 CH33-36 SLP98UH070V36B 4020627
XC16-024-230 TXV 25,200 14.20 11.70 CH33-36A 3068770
XC16-024-230 TXV 25,800 16.20 13.00 CH33-36B G61MPV-36B-045 3068833
XC16-024-230 TXV 25,800 16.50 13.00 CH33-36B G61MPV-36B-070 3068834
XC16-024-230 TXV 25,800 16.50 13.00 CH33-36B G61MPV-36B-071 3068836
XC16-024-230 TXV 25,000 14.20 11.70 CH33-36B 3068771
XC16-024-230 TXV 26,200 16.50 13.00 CH33-36C SLP98UH090V36C 4231106
XC16-024-230 TXV 26,200 16.70 13.20 CR33-30/36 G61MPV-36B-045 3068810
XC16-024-230 TXV 26,200 16.70 13.20 CR33-30/36 G61MPV-36B-070 3068811
XC16-024-230 TXV 26,200 16.70 13.20 CR33-30/36 G61MPV-36B-071 3068813
XC16-024-230 TXV 26,400 16.50 13.20 CR33-30/36 SL280DF070V36A 3932956
XC16-024-230 TXV 26,200 16.70 13.20 CR33-30/36 SLP98DF070V36B 4020628
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.
