SPECIFICATIONS
Model No. HS29-141 HS29-211 HS29-261 HS29-311
Ntf ft(
2
)
Outer coil 7.56 (0.70) 11.33 (1.05) 11.33 (1.05) 13.22 (1.23)
Condenser
Net face area - sq. ft. (m
2
)
Inner coil - - - - - - - - - - - - - - - -
Condenser
Coil
Tube diameter  in. (mm) & no. of rows 5/16 (7.9)  1 5/16 (7.9)  1 5/16 (7.9)  1 5/16 (7.9)  1
Fins per inch (m) 22 (866) 22 (866) 22 (866) 22 (866)
Diameter  in. (mm) & no. of blades 18 (457)  3 18 (457)  3 18 (457)  3 18 (457)  3
Motor hp (W) 1/6 (124) 1/6 (124) 1/6 (124) 1/6 (124)
Condenser
Fan
Cfm (L/s) 2400 (1135) 2400 (1135) 2400 (1135) 2460 (1160)
Fan
Rpm 1105 1105 1105 1125
Watts 180 180 180 170
*Refrigerant charge furnished (HCFC-22)
2 lbs. 12 oz.
(1.25 kg)
3 lbs. 10 oz.
(1.64 kg))
3 lbs. 13 oz.
(1.73 kg))
4 lbs. 5 oz. (1.96 kg)
Liquid line  in. (mm) o.d. connection (sweat) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Suction line  in. (mm) o.d. connection (sweat) 5/8 (15.9) 5/8 (15.9) 5/8 (15.9) 3/4 (19.1)
Shipping weight  lbs. (kg) 1 package 146 (66) 146 (66) 148 (67) 157 (71)
*Refrigerant charge sufficient for 20 ft. (6.1 m) length of refrigerant lines.
3/8x5/16 in. (9.5x7.9mm) adaptor furnished for liquid line connection.
SPECIFICATIONS (contd.)
Model No.
HS29-411
HS29-413
HS29-461
HS29-463
HS29-511
HS29-513
HS29-651
HS29-653
HS29-681
HS29-683
Net face area sq ft (m
2
)
Outer coil 15.11 (1.40) 15.11 (1.40) 15.11 (1.40) 15.21 (1.41) 21.11 (1.96)
Condenser
Net face area - sq. ft. (m
2
)
Inner coil - - - - 5.40 (0.50) 5.44 (0.50) 14.0 (13.4) 20.3 (1.89)
Condenser
Coil
Tube diameter  in. (mm) & no. of rows
5/16 (7.9) 
1
5/16 (7.9)  1.37 5/16 (7.9)  1.37 5/16 (7.9)  2 5/16 (7.9)  2
Fins per inch (m) 22 (866) 22 (866) 22 (866) 22 (866) 22 (866)
Diameter  in. (mm) & no. of blades 18 (457)  4 18 (457)  4 18 (457)  4 18 (457)  4 18 (457)  4
Motor hp (W) 1/6 (124) 1/6 (124) 1/3 (249) 1/3 (249) 1/3 (249)
Condenser
Fan
Cfm (L/s) 2520 (1190) 2500 (1180) 2950 (1390) 2930 (1385) 2930 (1385)
Fan
Rpm 1100 1100 1100 1100 1100
Watts 200 200 310 310 310
*Refrigerant charge furnished (HCFC-22)
5 lbs. 0 oz.
(2.26 kg)
5 lbs. 9 oz. (2.52
kg)
6 lbs. 3 oz.
(2.81 kg)
7 lbs. 10 oz.
(3.46 kg)
12 lbs. 0 oz.
(5.44 kg)
Liquid line  in. (mm) o.d. connection (sweat) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Suction line  in. (mm) o.d. connection (sweat) 3/4 (19.1) 7/8 (22.2) 7/8 (22.2) 1-1/8 (28.6) 1-1/8 (28.6)
Shipping weight  lbs. (kg) 1 package 165 (75) 191 (87) 196 (89) 212 (96) 254 (115)
*Refrigerant charge sufficient for 20 ft. (6.0 m) length of refrigerant lines.
