Page 3
SPECIFICATIONS (contd.)
Model No. HS29-012 HS29-018 HS29-024 HS29-030
Net face area sq ft (m
2
)
Outer coil 7.56 (0.70) 11.33 (1.05) 11.33 (1.05) 13.22 (1.23)
Condenser
Net face area - sq. ft. (m
2
)
Inner coil - - - - - - - - - - - - - - - -
Condenser
Coil
Tube diameter  in. (mm) & no. of rows 5/16 (7.9)  1 5/16 (7.9)  1 5/16 (7.9)  1 5/16 (7.9)  1
Fins per inch (m) 22 (866) 22 (866) 22 (866) 18 (748)
Diameter  in. (mm) & no. of blades 18 (457)  3 18 (457)  3 18 (457)  3 18 (457)  3
Cd
Motor hp (W) 1/6 (124) 1/6 (124) 1/6 (124) 1/6 (124)
Condenser
Fan
Cfm (L/s) 2400 (1135) 2400 (1135) 2400 (1135) 2545 (1201)
Fan
Rpm 1105 1105 1105 1110
Watts 180 180 180 195
*Refrigerant charge furnished (HCFC-22)
3 lbs. 1 oz.
(1.38 kg)
3 lbs. 7 oz.
(1.55 kg)
3 lbs. 10 oz.
(1.64 kg)
4 lbs. 1 oz.
(1.83 kg)
Liquid line  in. (mm) o.d. connection (sweat) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Suction line  in. (mm) o.d. connection (sweat) 5/8 (15.9) 5/8 (15.9)
5/8 (15.9) −1, −2 units
3/4 (19) −3 units
3/4 (19.1)
Shipping weight  lbs. (kg) 1 package 146 (66) 146 (66) 148 (67) 140 (64)
*Refrigerant charge sufficient for 15 ft. (4.5 m) length of refrigerant lines. 3/8 x 5/16 in. (9.5 x 7.9 mm) adaptor furnished for liquid line connection.
SPECIFICATIONS (contd.)
Model No. HS29-036 HS29-042 HS29-048 HS29-060
Net face area sq ft (m
2
)
Outer coil 15.11 (1.40) 15.11 (1.40) 15.11 (1.40) 15.11 (1.40)
Condenser
Net face area - sq. ft. (m
2
)
Inner coil - - - - 5.40 (0.50) 5.40 (0.50) 14.40 (1.34)
Condenser
Coil
Tube diameter  in. (mm) & no. of rows 5/16 (7.9)  1 5/16 (7.9)  1.37 5/16 (7.9)  1.37 5/16 (7.9)  2
Fins per inch (m) 22 (866) 18 (748) 18 (748)
Diameter  in. (mm) & no. of blades 18 (457)  4 18 (457)  4 18 (457)  4 18 (457)  4
Condenser
Motor hp (W) 1/6 (124) 1/6 (124) 1/3 (249) 1/3 (249)
Condenser
Fan
Cfm (L/s) 2520 (1190) 2610 (1232) 3115 (1470) 3010 (1420)
Fan
Rpm 1100 1105 1125 1125
Watts 200 200 325 315
*Refrigerant charge furnished (HCFC-22)
1 ph−4 lbs. 6 oz. (1.98 kg)
3 ph−4 lbs 13 oz. (2.17 kg)
1 ph−5 lbs. 7 oz. (2.45 kg)
3 ph−5 lbs 6 oz. (2.43
1ph 5 lbs. 8 oz. (2.48 kg)
3ph 6 lbs 0 oz. (2.72)
1 ph 8 lbs. 0 oz. (3.62 kg)
3 ph 7 lbs 7 oz. (3.36)
Liquid line  in. (mm) o.d. connection (sweat) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Suction line  in. (mm) o.d. connection (sweat) 3/4 (19.1) 7/8 (22.2) 7/8 (22.2) 1-1/8 (28.6)
Shipping weight  lbs. (kg) 1 package 145 (66) 158 (72) 191 (87) 207 (94)
*Refrigerant charge sufficient for 15 ft. (4.5 m) length of refrigerant lines.
ELECTRICAL DATA
Model No. HS29-141 HS29-211 HS29-261 HS29-311 HS29-411 HS29-413
Line voltage data  60 hz
208/230v
1ph
208/230v
1ph
208/230v
1ph
208/230v
1ph
208/230v
1ph
208/230v
3ph
460v
3ph
Rated load amps 4.9 8.6 10.1 11.8 17.5 10.3 4.3
Compressor Power factor .97 .97 .96 .92 .90 .83 .83
Locked rotor amps 26.3 48.3 60.0 69.4 96.0 75.0 40.0
Condenser Coil
Full load amps 1.1 1.1 1.1 1.1 1.1 1.1 0.55
Condenser
Coil
Fan Motor
Locked rotor amps 1.9 1.9 1.9 1.9 1.9 1.9 1.0
Rec. maximum fuse or circuit breaker size (amps) 15 15 20 25 40 20 10
*Minimum circuit ampacity 7.3 11.0 13.8 15.9 23.8 14.0 6.5
*Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
NOTE  Extremes of operating range are plus 10% and minus 5% of line voltage.
