n.ConnecttheLVDScabletotheconnectoronthemotherboard.
o.AttachtheEMIcovertothenewLCDmodule.
p.LineuptheopticalhousingwiththeguidetrackontheLCDmodule,thenslidethehousing
intopositionandsecurethehousingwiththethreescrews.
q.AttachtheharddiskdrivetothenewLCDmodule.
r.SecuretherearcovertothenewLEDmodulewiththesixscrews.
s.Attachthehingetothechassisandsecureitwiththefourscrews.
t.Lineupthefootcoverwithrearcover,thenslidethefootcoverintoposition.
Step26.Reattachthestandbasewithhinge.
ReplacingtheLCDpanelmodule-NoneT ouch
Note:Turnoffthecomputerandwait3to5minutestoletitcooldownbeforeremovingthecover.
Note:Itmaybehelpfultoplacethecomputerface-downonasoftflatsurfaceforthisprocedure.Lenovo
recommendsthatyouuseablanket,towel,orothersoftclothtoprotectthecomputerscreenfromscratches
orotherdamage.
ToreplacetheLCDpanelmodule:
Step1.Removeanymedia(disks,CDs,DVDs,ormemorycards)fromthedrives,shutdowntheoperating
system,andturnoffthecomputerandallattacheddevices.
Step2.Unplugallpowercordsfromelectricaloutlets.
Step3.Disconnectallcablesattachedtothecomputer.Thisincludespowercords,input/output(I/O)
cables,andanyothercablesthatareconnectedtothecomputer.Referto“Leftandrightview”
and“Rearview”forhelpwithlocatingthevariousconnectors.
Step4.Removethestandbase.Referto“Removingthestandbase”.
Step5.Removethefootcover.Referto“Removingthefootcover”.
Step6.Removethehinge.Referto“Removingthestandhinge” .
Step7.Removetheharddiskdrive.Referto“Replacingharddiskdrive”.
Step8.Removetheopticaldrive.Referto“Replacingtheopticaldrive” .
Step9.Removetherearcover.Referto“Removingtherearcover”.
Step10.Removethepowerswitchboard.Referto“Replacingthepowerswitchboard”.
Step11.Removetheconverterboard.Referto“Replacingtheconverterboard”.
Step12.RemovetheEMIcover.Referto“RemovingtheEMIcover”.
Step13.Removethespeakersystem.Referto“Replacingthespeakersystem”.
Step14.Removethecamera.Referto“Replacingthecamera” .
Step15.Removetheseventeenscrewsthatsecurethechassistothefrontbezel.
