Miscellaneous parts
Table 39. Parts list—Miscellaneous parts
FRU P/N RoHS
ID
CRU
ID
Screw kit for IdeaPad S9e and S10e:
v M2 × 2.5 mm (silver), wafer-head (10)
v M2 × 4.0 mm (silver), wafer-head (25)
v M2 × 6.0 mm (black), wafer-head (15)
v M3 × 3.5 mm (silver), wafer-head (5)
45N3867 R N
Screw kit for IdeaPad S10:
v M2 × 2.0 mm (silver), wafer-head (10)
v M2 × 2.5 mm (silver), wafer-head (10)
v M2 × 4.0 mm (silver), wafer-head (25)
v M2 × 6.0 mm (black), wafer-head (15)
v M3 × 3.5 mm (silver), wafer-head (5)
45N5921 R N
Misc parts kit (common) for IdeaPad S9e and S10e:
v (b) LCD bracket, Right
v (c) LCD bracket, Left
v (d) Hinge cap, Right
v (e) Hinge cap, Left
Note:
Italicized letters in parentheses are references to the
exploded view in “LCD FRUs” on page 114.
45N3863 R N
Misc parts kit (common) for IdeaPad S10:
v (b) LCD bracket, Right
v (c) LCD bracket, Left
v (d) Hinge cap, Right
v (e) Hinge cap, Left
Note:
Italicized letters in parentheses are references to the
exploded view in “LCD FRUs” on page 114.
45N5915
Rubber cap kit:
v Rubber cap, Top, black
v Rubber cap, Bottom, black
v Rubber cap, Top, white
v Rubber cap, Bottom, white
v Rubber cap, Rear, dark silver
v Rubber cap, Rear, blue
v Rubber cap, Rear, red
v Rubber cap, Rear, pink
v Rubber cap, Rear, white
v Rubber cap, Rear, black
45N5143 R N
Misc parts kit (dark sliver) for IdeaPad S9e and S10e:
v (a) HDD door, dark silver
v ExpressCard dummy, dark silver
Note:
Italicized letters in parentheses are references to the
exploded view in “Overall” on page 107.
45N5098 R N
Misc parts kit (blue) for IdeaPad S9e and S10e:
v (a) HDD door, blue
v ExpressCard dummy, blue
Note:
Italicized letters in parentheses are references to the
exploded view in “Overall” on page 107.
45N5099 R N
IdeaPad S9e, S10e, and S10 123
