Lenovo C24-20 User Manual

Chapter 2. 2-3
Adjusting your monitor image
This section describes the control features to adjust your monitor image.
Using the direct access controls
The direct access controls can be used when the On-Screen Display (OSD) is not displayed.
Icon Control Description
1
Input Source
Switches the video input source
Shift back to previous level when in OSD mode
Exit
Shortcut key for directly opening the menu of source-
selecting while there is no any OSD on the screen.
Press to exit current OSD or return to previous level.
Press and hold for 10 seconds, then the DDC/CI
function will be Enabled/Disabled.
2
Auto Adjustment
Optimizes image (size, position, phase and clock) (For
analog [VGA] source only)
Increase
Press to move to last item on menu.
Press to Increase current value on adjustment bar.
3
Brightness
Shortcut key for directly opening brightness adjustment
bar while there is no any OSD on the screen.
Enable Low Blue Light
Press and hold for 3 seconds to enable Low Blue Light
Disable Low Blue Light
Press and hold for 3 seconds to disable Low Blue Light
Decrease
Press to move to next item on menu.
Press to decrease current value on adjustment bar.
4
Menu/OK
Press to open main menu while there is no any OSD on
the screen.
Press to enter next level on main menu or sub menu , or
enter previous level on adjustment bar.
Press and hold for 10 seconds, then Main menu will be
Locked/un-Locked.
Enter
Press to enter next level on main menu/sub menu status
or enter previous level on adjustment bar

Lenovo C24-20 Specifications

General

Panel type	VA
Color depth	8 bit
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Pixel density	93 ppi
Response time	6 ms
Backlight type	W-LED
Display diagonal	23.8 \
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
Response time (fast)	4 ms
Supported video modes	1080p
NTSC coverage (typical)	72 %
Viewable size, vertical	296.46 mm
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
AMD FreeSync type	FreeSync
Product color	Black
HDMI version	1.4
DisplayPorts quantity	0
Tilt angle range	-5 - 22 °
Cable lock slot type	Kensington
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	47/63 Hz
Power consumption (max)	23 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Cables included	AC, HDMI
Package depth	124 mm
Package width	633 mm
Package height	405 mm
Package weight	4870 g

Weight and Dimensions

Bezel width (side)	2 mm
Depth (with stand)	206.2 mm
Height (with stand)	403.9 mm
Weight (with stand)	3010 g
Bezel width (bottom)	23.4 mm
Depth (without stand)	54.4 mm
Width (without stand)	540.1 mm
Height (without stand)	328.5 mm
Weight (without stand)	2700 g
