Lenovo C24-20 User Manual

Chapter 2. 2-11
Step 4: Attach the mounting bracket from the VESA compatible wall mounting kit
(100mm x100mm distance), the type of VESA mounting screw is M4 x 10 mm.
Step 5: Attach the LCD display to the wall, and follow the instructions in the wall-mounting
kit.
For use only with UL Listed Wall Mount Bracket with minimum weight/load: 8kg
Note: When you use a flexible arm, do not tilt the monitor downward by more than 5 degrees.
VESA hole

Lenovo C24-20 Specifications

General

Panel type	VA
Color depth	8 bit
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Pixel density	93 ppi
Response time	6 ms
Backlight type	W-LED
Display diagonal	23.8 \
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
Response time (fast)	4 ms
Supported video modes	1080p
NTSC coverage (typical)	72 %
Viewable size, vertical	296.46 mm
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
AMD FreeSync type	FreeSync
Product color	Black
HDMI version	1.4
DisplayPorts quantity	0
Tilt angle range	-5 - 22 °
Cable lock slot type	Kensington
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	47/63 Hz
Power consumption (max)	23 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Cables included	AC, HDMI
Package depth	124 mm
Package width	633 mm
Package height	405 mm
Package weight	4870 g

Weight and Dimensions

Bezel width (side)	2 mm
Depth (with stand)	206.2 mm
Height (with stand)	403.9 mm
Weight (with stand)	3010 g
Bezel width (bottom)	23.4 mm
Depth (without stand)	54.4 mm
Width (without stand)	540.1 mm
Height (without stand)	328.5 mm
Weight (without stand)	2700 g
