Chapter 9. FRU lists
This chapter lists the information on the field replaceable units (FRUs) for Lenovo ideacentre 510 and 510A
series computers.
Attention: Be sure to read and understand all the safety information before replacing any FRUs.
Notes: FRUs that have a 1 or 2 in the CRU column are Customer Replaceable Units (CRUs).
• 1– identifies parts that are fairly simple to replace, requiring few or no tools.
• 2– identifies parts that are slightly more difficult to replace.
• N-identifies parts that are not to be replaced by the customer.
NO. FRU CRU No.
1
Side chassis
1
2 Memory 1
3 Front cover 1
5
ODD
1
6
ODD Bracket
1
7
ODD cable N
8 HDD 1
9 3.5 " HDD Bracket 1
10
2.5" HDD/SSD Bracket
1
11
HDD Cable
N
12 Power switch cable N
13
Power Supply
2
14 Fan + Heat sink N
15 Thermal sensor cable N
16
Graphic card
1
18 Mechanical chassis N
Rubber block
cable organizer *4
rubber foot*2
19
CPU
N
20
Mother board FRU=Mother board+Cmos battery+CPU Holder
N
Mother board
Cmos battery
CPU Holder
21
SSD
1
22
Power Cord
1
© Copyright Lenovo 2017 49
