Lenovo ThinkPad Universal USB-C Dock User Manual

Chapter 3. Use the dock
Use the video output connectors
The dock has three video output connectors to support up to three external displays:
• Two DisplayPort connectors (support DisplayPort 1.4)
• One HDMI connector (supports HDMI 2.0)
Supported resolution
Depending on the USB-C connector or Thunderbolt 3 connector on your computer, the dock supports the
following display resolutions:
• One / two video output connectors: up to 3840 x 2160 pixels / 60 Hz
• Three video output connectors: up to 3840 x 2160 pixels / 30 Hz
To view the maximum display matrix, go to
https://support.lenovo.com/us/zh/solutions/pd029622#USB-
C%20dock
and select the entry for the dock.
Configure the external displays
You can configure the external displays connected to your dock:
• Set the display mode: extend, mirror or duplicate, or single display.
• Set the orientation, brightness, resolution, color, and more.
To configure the external displays:
1. Right-click a blank area on the desktop and select Display settings.
2. Select the display that you want to configure.
3. Configure display settings of your preference.
For more information, see the Windows help information.
Use the Ethernet connector
You can use the Ethernet connector on the dock to connect your computer to a standard 10 Mbps, 100
Mbps, or 1000 Mbps network with an Ethernet cable.
The Ethernet connector has two network status indicators. When the green indicator is on, the computer is
connected to a LAN. When the yellow indicator blinks, data is being transmitted.
Depending on your computer, some of the following functions are available when the dock is connected to a
LAN.
• Preboot eXecution Environment
• MAC address Pass Through
• Wake on LAN
• Wake on LAN from Dock
© Copyright Lenovo 2021 7

Lenovo ThinkPad Universal USB-C Dock Specifications

General

Microphone in	No
USB 2.0 ports quantity	2
Connectivity technology	Wired
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Power supply	90 W
Power connector	USB Type-C
Power source type	USB
Windows operating systems supported	Windows 10, Windows 7
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 95 %
Sustainability certificates	CE
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Package depth	158 mm
Package width	210 mm
Package height	75 mm
Package weight	955 g
Quantity per pack	1 pc(s)
Certification	FCC/ICES, KCC, RCM, BSMI, VCCI, CB, cULus, EAC, TUV- Mark, Kvalitet, LoA, Israel SII, DoC, NOM
Product color	Black
Cable lock slot type	Kensington
Maximum digital resolution	3840 x 2160 pixels
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	80 mm
Width	171 mm
Height	30.75 mm
Weight	340 g
