Wirin g accord ing to EM C
Always observe these basic rules
13
l EDBEMV82EV EN 3.0
If at all possible do not rip open the motor cable
Cuts in the motor cable due to contactors or switches are potential interfering radiators since the
motor cable shield is interrupted. For this reason please avoid to rip open the motor cable.
If it is indispensable to rip open the motor cable, the following must be observed:
z Connect the shield directly before and behind the cut to the mounting plate with a surface as
large as possible. Do not exceed an unshielded cable length of max. 40 mm.
z Install the cut points with a distance of at least 100 m to the other components on the
mounting plate.
z If EMC interferences occur check whether an additional motor interference suppression
module is required.
Assignment table of motor interference suppression module
Motor interference suppression module
Application with 8200 vector
Type U
N
Type
[V]
E82ZM37132B002 240
E82xV251K2
E82xV371K2
E82ZM75134B004
E82xV551Kx
E82xV751Kx
E82ZM22234B004
E82xV152Kx
E82xV222Kx
E82ZM11334B004
400
E82xV302Kx
E82xV402Kx
E82xV552Kx
E82xV752Kx
E82xV113K4
E82ZM75134B005
E82xV551K4
E82xV751K4
E82ZM22234B005
E82xV152K4
E82xV222K4
E82ZM11334B005
500 E82xV302K4
E82xV402K4
E82xV552K4
E82xV752K4
E82xV113K4
