Technical Data
3-4 UOMu_^MVMO
3.3 Fuses and cable cross-sections
3.3.1 Single drives with 150 % overload
qÜÉ í~ÄäÉ î~äìÉë ~êÉ î~äáÇ Ñçê íÜÉ çéÉê~íáçå çÑ UOuu ÅçåíêçääÉêë ~ë
ëáåÖäÉ ÇêáîÉë ïáíÜ ~ ã~íÅÜáåÖ ãçíçê ~åÇ NRM B çîÉêäç~ÇK
Type
Mains input L1, N, PE / motor connection U, V, W, PE
Operation without mains filter/mains choke Operation with mains filter/mains choke
Fuse
F1, F2, F3
E.l.c.b. Cable
cross-section
1)
Fuse
F1, F2, F3
E.l.c.b. Cable
cross-section
1)
VDE UL VDE mm
2
AWG VDE UL VDE mm
2
AWG
8201 M 10A - C 10A 1.5 15 M 10A - C 10A 1.5 15
8202 M 15A - C 16A 2.5 13 M 15A - C 16A 2.5
[1.5]
13
[15]
8203 M 20A - C 20A 4 11 M 15A - C 16A 2.5
[1.5]
13
[15]
8204 - - - - - M 20A - C 20A 4
[2.5]
11
[13]
Values in square brackets are valid for motor connection
1)
Observe national and regional regulations (e. g. VDE/EVU)!
3.4 Dimensions
qÜÉ ÅçåíêçääÉê ÇáãÉåëáçåë ÇÉéÉåÇ çå íÜÉ ãÉÅÜ~åáÅ~ä áåëí~ää~íáçå
EëÉÉ ÅÜ~éíÉê QKNFK
