1 About this documentation
1.2 Conventions used
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
1.2 Conventions used
This documentation uses the following conventions to distinguish between different types of
information:
Type of information Highlighting Examples/notes
Spelling of numbers
Decimal Normal spelling Example: 1234
Decimal separator Point The decimal point is always used.
For example: 1234.56
Hexadecimal 0x[0 ... 9, A ... F] Example: 0x60F4
Binary
• Nibble
In inverted commas
Point
Example: ’100’
Example: ’0110.0100’
Text
Version information Blue text colour All information that applies to from a certain software
version of the device onwards is marked accordingly in this
documentation.
Example: This function extension is available from software
version V3.0!
Program name » « The Lenze »Engineer« PC software...
Control element Bold The OK button... / the Copy command... / the Characteristics
tab... / the Name input field...
Sequence of menu
commands
If several commands are required in succession for executing
a function, the single commands are separated by an arrow:
Select the File
 Open command to...
Hyperlink Underlined
Optically highlighted reference to another topic. It is
activated with a mouse-click in this online documentation.
Icons
Page reference ( 9) Optically highlighted reference to another page. It is
activated with a mouse-click in this online documentation.
Step-by-step instructions

Step-by-step instructions are indicated by a pictograph.
