Lenze EMF2173IB User Manual

EDK2173DB DE/EN/FR 5.1
14
l
legende_kopfzeile−TIP_download_EN
Legend for fold−out page See
0
Voltage adapter for keyboard connection
l for EMF2173IB: design with DIN plug
l for EMF2173IB−V002 /−V003: design with PS2 plug
^ 20
1
Connection cable (cable length approx. 900 mm)
2
Connection to parallel LPTx interface
3
Keyboard cable with plug
4
Connection to keyboard input
5
Sub−D plug with 3−pole cable
6
Use the grey/green plugs or the green adapter contained in the scope of supply
for the following controllers:
l Green 3−pole adapter:
8200 vector frequency inverter with E82ZAFC function module
l Green 4−pole plug:
8200 vector frequency inverter with 2171/2172communication module
l Grey 3−pole plug:
93XX servo inverter, 9300 servo PLC
7
9400servo drives
8
93XX servo inverter, 9300 servo PLC
9
ECS servo system
l Please use the plug contained in the scope of supply of the controller.
:
Drive PLC
l Please use the plug contained in the scope of supply of the controller.
;
8200 vector frequency inverter
Witho
ut
illustr
ation
82XX frequency inverter
l with communication module of type 2171 or 2172:
Use green 4−pole plug!
l with communication module of type 2175 or 2178:
Use green 5−pole plug contained in the scope of supply of the
communication module!
0Fig. 0Tab. 0
I Tip!
Current documentation and software updates concerning Lenze products can
be found on the Internet in the "Services & Downloads" area under
http://www.Lenze.com
