Lenze 13466184 EDBSL03 v20 EN, DE, FR, IT, ES 11
Installation
Terminal Data for control connections (printed in bold = Lenze setting)
71
RS-485 serial communication input RXB/TXB (B+)
72
RS-485 serial communication input RXA/TXA (A-)
7
Reference potential
8
Analog input
0 … 10 V (changeable under C34)
input resistance: >50 kΩ
(with current signal: 250Ω)
9
Internal DC supply for setpoint potentiometer +10 V, max. 10 mA
20
Internal DC supply for digital inputs +12 V, max. 20 mA
28
Digital input Start/Stop LOW = Stop HIGH = Run Enable
R
i
= 3.3 kΩ
E1
Digital input congurable with CE1
Activate fixed setpoint 1 (JOG1)
HIGH = JOG1 active
E2
Digital input congurable with CE2
Direction of rotation
LOW = CW rotation
HIGH = CCW rotation
E3
Digital input congurable with CE3
Activate DC injection brake (DCB)
HIGH = DCB active
A1
Digital output congurable with c17 DC 24 V / 50 mA; NPN
62
Analog output congurable with c08 & c11
K14
Relay output (normally-open contact)
Congurable with C08
Fault (TRIP)
AC 250 V / 3 A
DC 24 V / 2 A … 240 V / 0.22 A
K12
LOW = 0 … +3 V, HIGH = +12 … +30 V
Protection against contact
• All terminals have basic isolation (single insulating distance)
• Protection against contact can only be ensured by additional measures (i.e. double insulation)
STOP!
In the case of a Spinning Motor:
To bring free-wheeling loads such as fans to a rest before starting the drive, use the DC
injection braking function (“Auto-DCB”). Starting a drive into a freewheeling motor creates
a direct short-circuit and may result in damage to the drive.
Conrm motor suitability for use with DC injection braking.
3.2.4 Control terminals
STOP!
If the kVA rating of the AC supply transformer is greater than 10 times the input kVA rating of the drive(s),
an isolation transformer or 2-3% input line reactor must be added to the line side of the drive(s).
