Commissioning and operation
Important notes
6
38
Lenze ¯ MA 12.0012 ¯ 4.0
6 Commissioning and operation
6.1 Important notes
Stop!
The drive may only be commissioned by skilled personnel!
¯ Before commissioning remove transport locking devices and keep them for later
transports.
¯ Take safety measures prior to any operation:
– Disconnect the machine from the mains, ensure standstill of the drive system
and avoid any machine movement.
– That the ambient temperature match the data on the nameplate.
Follow the instructions specified for the temperature ranges.
Temperature range
Standard
Ambient temperature 0 °C ... +40 °C
Lubricant Mineral oil
¯ CLP 460
Synthetic oil
¯ CLP HC 220
Food−compatible oil
¯ CLP PG 460 USDA H1
Note At an ambient temperature mainly above +30 °C
¯ Application case must be verified by Lenze
Low−temperature
Ambient temperature −30 °C ... +10 °C
Lubricant Food−compatible oil
¯ CLP HC 46 USDA H1
Note When starting up a cold motor, increased starting torques are to be expected at
temperatures below −20 °C due to the higher viscosity of the roller bearing grease.
¯ During project planning, allow a motor starting torque reserve of about 20 %.
Commissioning at over +10 °C:
¯ Operate the drive at max. 50 % of the rated torque to avoid a reduction in service life.
Wide range
Ambient temperature −30 °C ... +40 °C
Lubricant Synthetic oil
¯ CLP HC 220
Note When starting up a cold motor, increased starting torques are to be expected at
temperatures below −20 °C due to the higher viscosity of the roller bearing grease.
¯ During project planning, allow a motor starting torque reserve of about 30 %.
At an ambient temperature mainly above +30 °C:
¯ Individual case must be verified by Lenze!
At a continuous temperature of between −30 °C and −25 °C, the service life is up to 20 %
shorter than with the low−temperature range.
Tab. 5 Temperature range
