Electrical installation
Wiring and Configuration
MC−ETC, MC−ETH
4
l
28
BA_MC−Card EN 1.0
4.3.2 MC−ETC, MC−ETH
Wiring
Description Connection type Cable type
SPEED
LINK
LAN
MC−ETH port
"Link" LED:
On: Connection OK
Blinking: Data transfer
"Speed" LED:
Off: 10 Mbps
Green: 100 Mbps
Yellow: 1000 Mbps
MC−ETC port
"Link" LED:
On: Connection OK
Blinking: Data transfer
"Speed" LED:
Green: 100 Mbps
RJ45 socket
CAT5 S/UTP or CAT5e S/FTP
(recommended) network
cable, max. cable length
100 m
MC−ETH−003
) Note!
If the RJ45 plug connection is exposed to oscillating or vibrating stress:
ƒ Use a strain relief in the immediate vicinity of the RJ45 socket.
ƒ Select the contact surface on which the device is mounted as fixing point of
the strain relief.
ƒ Comply with the related minimum bending radius of the cable used.
Use of the MC card in Windows
â
XP or Windows
â
Embedded Standard 2009
In order to use the communication card in Windows
â
XP, a device driver is required. It is
already pre−installed and also included on the "PC based Automation" DVD. For the
implementation of the communication card in your own applications, use "WinSockets",
which are provided by corresponding programming systems. A special library is not
required.
) Note!
Addressing the communication card from your own applications requires
special programming skills. Lenze does not offer any support regarding this
matter. However, we can refer you to service providers who execute
customised programming and are familiar with Lenze Industrial PCs.
