Lexicon DC-1 User Manual

47
DC-1 Version 4 Digital Controller
AC-3 Effects and Parameters
5.1 Logic 7
5.1 Logic 7 combines all the features of Dolby Digital AC-3 with enhance-
ments by Lexicon and LucasFilm. This effect uses Logic 7 matrix technology
to enhance the steering between the side speakers and the rear speakers, so
sounds intended to come from behind the listener actually do come from
behind. This effect also includes the adaptive decorrelation and re-equal-
izer features of THX 5.1.
5.1 Logic 7 provides the ultimate in film reproduction. It brings out all the
increased excitement and spaciousness a 7 channel speaker system can
produce.
Parameter Initial Value Range
AC-3 STATUS (display only — not user adjustable)
COMPRESSION OFF AUTO, ON, OFF
VOCAL ENHANCE +0.0dB +0.0dB, +3.0dB, +6.0dB
RE-EQUALIZER ON ON, OFF
BASS ENHANCE OFF ON, OFF
REAR DELAY OFFSET 5ms 0-20ms
SIDE LEVEL +00dB OFF, -30dB to +05dB
REAR LEVEL +00dB OFF, -30dB to +05dB
LFE MIX LEVEL +0.0dB -10.0dB to 0.0dB
SUBWOOFER LVL +00dB OFF, -30dB to +05dB
CUSTOM
Dolby Digital
The Dolby Digital effect decodes Dolby AC-3 encoded soundtracks. Unlike
analog Dolby surround decoding, Dolby Digital uses five discrete full-
range channels and a sixth dedicated, Low Frequency Effect (LFE) channel.
In this effect, any rear speakers present are connected in parallel with the
side speakers. This is the standard Dolby Digital decoder. It does not
include the enhancements by Lexicon or LucasFilm which are available
with other AC-3 effects in the DC-1.
Parameter Initial Value Range
AC-3 STATUS (display only — not user adjustable)
COMPRESSION OFF AUTO, ON, OFF
VOCAL ENHANCE +0.0dB +0.0dB, +3.0dB, +6.0dB
BASS ENHANCE OFF ON, OFF
SIDE LEVEL +00dB OFF, -30dB to +05dB
REAR LEVEL +00dB OFF, -30dB to +05dB
LFE MIX LEVEL +0.0dB -10.0dB to +0.0dB
SUBWOOFER LVL +00dB OFF, -30dB to +05dB
CUSTOM
