Lexmark MS410dn User Manual

Printer model Height Width Depth Weight with cartridge
and imaging unit
(unpackaged)
MS610de 305.9 mm (12.1 in.) 399 mm (15.7 in.) 396.5 mm (15.6 in.) 16.2 kg (35.7 lb)
MS610dte 414 mm (16.3 in.) 399 mm (15.7 in.) 396.5 mm (15.6 in.) 20.9 kg (46.1 lb)
Multifunction printer dimensions (unpackaged)
Printer model Height Width Depth Weight
(unpackaged, no options)
MX310dn, MX410de 468 mm (18.4 in.) 399 mm (15.7 in.) 472 mm (18.6 in.) 20 kg (44 lb)
MX510de, MX511de, MX511dhe 502 mm (19.8 in.) 489 mm (19.3 in.) 452 mm (17.8 in.) 21.8 kg (48 lb)
MX510dte 610 mm (24.0 in.) 489 mm (19.3 in.) 452 mm (17.8 in.) 26.5 kg (58.4 lb)
MX610de, MX611de, MX611dhe 561 mm (22.1 in.) 489 mm (19.3 in.) 479 mm (18.9 in.) 23.6 kg (52 lb)
MX611dte 669 mm (26.3 in.) 489 mm (19.3 in.) 479 mm (18.9 in.) 28.3 kg (62.4 lb)
Dimensions of the MS310, MS312, MS315, MS410, MS415, MS510, MS610, MX310, MX410, MX51x, MX61x
hardware options
Option Height Width Depth Weight
Footprint 389 mm (15.3 in.) 382 mm (15 in.)
Input options
550‑sheet tray 109 mm (4.3 in.) 389 mm (15.3 in.) 382 mm (15 in.) 4.7 kg (10.4 lb)
250‑sheet tray 77 mm (3 in.) 389 mm (15.3 in.) 382 mm (15 in.) 4.2 kg (9.3 lb)
Furniture options
Adjustable printer stand 584.2 mm (23 in.) 596.9 mm (23.5 in.) 596.9 mm (23.5 in.) 25 kg (55 lb)
Swivel cabinet (for
MS310, MS312, MS315,
MS410, MS415, MS510,
MS610 only)
263 mm (10.4 in.) 476 mm (18.7 in.) 600 mm (23.6 in.) 21.8 kg (48 lb)
Output option
Stapler (for MX61x
only)
*
195 mm (7.7 in.) 409 mm (16.1 in.) 371.5 mm (14.6 in.) 24.9 kg (55 lb)
*
Stapler adds 2.5 inches to the depth of the printer.
Clearance requirements
Note: These clearance values are for the most compact operating configuration of the product. Additional clearance
(especially from the front) may be needed to utilize the multipurpose feeder, clear paper misfeed, lift the scanner lid (for
MFPs only), or replace toner and imaging unit.
Clearance requirements for the SFP
Printer model Left side Right side Front Rear Top
MS310, MS312,
MS315, MS410,
MS415, MS510,
MS610
65 mm (2.56 in.) 110 mm (4.33 in.) 305 mm (12 in.) 100 mm (3.94 in.) 305 mm (12 in.)
Printer specifications 18

Lexmark MS410dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Security algorithms	802.1x RADIUS, LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)	TCP/IP, AppleTalk, UDP, TCP
Supported network protocols (IPv6)	TCP/IP
Printing colors	Black
Maximum duty cycle	80000 pages per month
Recommended duty cycle	750 - 7200 pages per month
Number of print cartridges	1
Page description languages	PCL 5Ce, PCL 6, PostScript 3, XML
Internal memory	256 MB
Processor frequency	800 MHz
Sound power level (standby)	15 dB
Sound pressure level (printing)	54 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 24 lbs
Standard interfaces	USB 2.0
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Power consumption (printing)	- W
Package weight	15900 g
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systems	Mac OS X 10.5, 10.6, 10.7, 10.8\\r Windows XP (32/64-bit)\\r Windows Server 2003 (32/64-bit)\\r Windows Vista (32/64-bit)\\r Windows Server 2008 (32/64-bit)\\r Windows 7 (32/64-bit)\\r Windows Server 2008 R2\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r Linpus Linux Desktop 9.6\\r Debian GNU/Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu 11.04, 11.10, 12.04\\r openSUSE 11.3, 11.4, 12.1\\r PCLinuxOS 2011.9\\r Mint 9, 10, 11, 12\\r Fedora 14, 15
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	CAN/CSA, CSA, ICES, BSMI, CNS, VCCI, US FDA, FCC, UL, IEC, EN/IEC, CE, CB IEC, EN, GS TUV, SEMKO, UL AR, CS, TUV Rh, SMA C-tick, CCC, CISPIR, EK Mark, N Mark, ECMA, TED
Product color	Black, White
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Weight	14100 g
Dimensions (WxDxH)	399 x 381 x 262 mm
