ENG

ENGLISH

CUSTOMIZING SETTINGS


Press

MENU button on the bottom of the Monitor set

to display the Menu OSD.

Select the "

Next Menu" button to enter the more

option settings.

Enter to

Picture by pressing the ▼ button.

Set the options by pressing the ◄ or ► or ▼

buttons.

Select

EXIT to leave the OSD menu.

To return to the upper menu or set other menu items,

use the up arrow (

) button.

Each option is explained below.

Menu > Next Menu > Picture Description

Sharpness To adjust the clearness of the screen.

Black Level

22MP48HQ 24MP48HQ

23MP48HQ 27MP48HQ

Sets the offset level (for HDMI only).

Offset: as a reference for a video signal, this is the darkest color the moni-

tor can display.

High Keeps the current contrast ratio of the screen.

Low Lowers the black levels and raises the white levels from the

current contrast ratio of the screen.

Overscan

22MP48HQ 24MP48HQ

23MP48HQ 27MP48HQ

To select the range of output image for DTV timing in HDMI input.(only for HDMI

input)Recommend overscan function to turn on when connect AV equipment.

Questions and Answers:

Need help?

Do you have a question about the LG 22MP48HQ and is the answer not in the manual?

LG 22MP48HQ Specifications

General

3D	No
Color gamut	72 %
Screen shape	Flat
Display surface	Matt
Display diagonal	21.5 \
Display technology	LED
Native aspect ratio	16:9
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
AC adapter included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	85 kWh
Power consumption (standby)	0.3 W
Power consumption (typical)	23 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Certification	TCO (6.0), TUV-Type, UL (cUL), RCM
Product color	Black
Panel mounting interface	75 x 75 mm
Cables included	AC, HDMI, VGA
