9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Setting up the Monitor set
Attaching the Stand Base
1
Please put a soft cloth on a low table or box
to protect the screen of the monitor.
Please put the monitor on the soft cloth with
the screen facing down.
2
Please grab the
Stand body
in one hand, and
push it in the direction of the arrow to
hinge
body
.After assembling, you must check if the
Stand body
latched in or not.
3
Please push the
Stand Base
in the direction
of the arrow as shown below and assemble
together.
Please use a driver(-) or coin to insert thumb
screw and turn right arrow direction lock.
* It is necessary to thoroughly tighten it with
Thumb Screw
, or the monitor will shake.
4
Please set the Monitor upright, and install the
necessary cable.
* Must use one type input cable. Don't use
more than two types cable together.
1
2
1
2
Stand body
Stand Base
To Next Page
