LG 24BK550Y User Manual

25
ENG
ENGLISH
SPECIFICATIONS
24BK550Y
LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display)
Panel,Anti-Glare coating
Pixel Pitch 0.2745 mm x 0.2745 mm
Resolution Maximum Resolution 1920 x 1080 @ 60 Hz
Recommended Resolution 1920 x 1080 @ 60 Hz
Video Signal Horizontal Frequency 30 KHz to 83 KHz
Vertical Frequency 56 Hz to 75 Hz
Synchronization Separate Sync.
Input Connector D-SUB IN, DVI-D IN, HDMI IN, DP(DisplayPort) IN, AUDIO IN(PC), H/P, USB UP, USB
IN1, USB IN2
Power consump-
tion
On mode: 17.1 W Typ. ( ENERGY STAR® standard ) *
23.6 W Typ. ( Outgoing condition ) **
Sleep Mode ≤ 0.5 W ( Outgoing condition )
Off Mode ≤ 0.3 W
Power Input AC 100-240V ~ 50/60Hz 1.2 A
Environmental
Conditions
Operating Temperature
Operating Humidity
0 °C to 40 °C (32 °F to 104 °F)
Less than 80 %
Storage Temperature
Storage Humidity
-20 °C to 60 °C (-4 °F to 140 °F)
Less than 85 %
Dimension Monitor Size (Width x Height x Depth)
With Stand 553.8 mm x 512.9 mm x 240 mm
Without Stand 553.8 mm x 333.1 mm x 58.4 mm
Weight (Without
Packaging)
5.7 kg
Product specifications shown above may be changed without prior notice due to upgrade of product functions.
* The power consumption level can be different by operating condition and monitor setting.
* The On mode power consumption is measured with ENERGY STAR
®
test standard.
** The On mode power consumption is measured with LGE test standard ( Full White pattern , Maximum
resolution).

LG 24BK550Y Specifications

General

3D	No
DDC/CI	Yes
Color gamut	72 %
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Display diagonal	24 \
Display technology	LED
Native aspect ratio	16:9
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	18
Panel mounting interface	100 x 100 mm
USB hub version	2.0
Number of upstream ports	1
USB Type-A downstream ports quantity	2
Sustainability certificates	EPEAT Gold, ENERGY STAR
RMS rated power	2 W
On/off switch	-
Certification	TCO 7.0, UL (cUL), TUV-GS, TUV-Ergo, FCC-B, THIS, ISO13406-2, Windows 10
Product color	Black
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18.2 W
Power consumption (PowerSave)	- W
Package depth	178 mm
Package width	627 mm
Package height	505 mm
Package weight	7900 g
Cables included	AC, Audio (3.5mm), DVI, DisplayPort, HDMI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	240 mm
Width (with stand)	553.8 mm
Height (with stand)	382.9 mm
Weight (with stand)	5700 g
Depth (without stand)	58.4 mm
Height (without stand)	331.8 mm
Weight (without stand)	3600 g
