LG 24BL450Y User Manual

- 7 - Copyright © 2018 LG Electronics Inc. All rights reserved.
Only training and service purposes
BLOCK DIAGRAM
RTD2536R
(Realtek)
8M
SERIAL
Flash
LED PANEL
LVDS
PWM_
DIM
F/B
SPI
Data/
CLK
DP_TMDS
Aux
USB2.0
Down Stream
USB2.0
UP Stream
USBGL850G
-33
APA2068
(Anpec)
Audio
IN
Speaker
KEY0/1
WLED_
EN
Crystal
12MHz
RST
Analog Sound(L/R)
2Ch. LDO
Core 1.1V
19V
System 3.3V
3.3V DP
HP
L/R
out
H/P
DP
HDMI
Aux
HDMI-TMDS
KEY0/1
Crystal
14.318MHz
