18
Specications
Product specications may be changed without prior notice due to upgrade of product functions.
Models
Dimensions (W x H x D) (mm) Weight (kg)
Power consumption
(Outgoing condition)
Power
requirement
With stand Without stand With stand Without stand
22TK410D
22TK410V
507.6 x 358.0 x 146.3 507.6 x 316.5 x 52.7 3.0 2.9 26 W 19 V 1.6 A
24TK410D
24TK410V
24TK410U
556 x 392.7 x 143.4 556 x 345.2 x 54.7 3.5 3.2 28 W 19 V 1.6 A
24TK420V 556 x 376.5 x 130.5 556 x 345.2 x 54.7 3.3 3.2 28 W 19 V 1.6 A
28TK410D
28TK410V
28TK410U
641.5 x 444.0 x 178.8 641.5 x 396.3 x 59.5 5.0 4.5 28 W 19 V 1.6 A
28TK420V 641.5 x 428.7 x 159.2 641.5 x 396.3 x 59.5 4.6 4.5 28 W 19 V 1.6 A
AC/DC Adapter
Manufacturer : Lien Chang
Model : LCAP16A-E, LCAP21A
Manufacturer : Honor
Model : ADS-40FSG-19 19032GPG,
ADS-40SG-19-3 19032G
In : AC 100 – 240 V ~ 50/60 Hz
Out : DC 19 V 1.7 A
CI module Size (W x H x D) 100.0 mm x 55.0 mm x 5.0 mm
Environment
condition
Operating Temperature 0 °C to 40 °C
Operating Humidity Less than 80 %
Storage Temperature -20 °C to 60 °C
Storage Humidity Less than 85 %
