LG 27MK430H User Manual

13
ENG
ENGLISH
Mounting on a wall
For proper ventilation, allow a clearance of 100
mm(3.94 inches) on each side and from the wall.
Detailed instructions are available from your dealer, see
the optional Tilt Wall Mounting Bracket Installation and
Setup Guide.
If you intend to mount the Monitor set to a wall, attach
Wall mounting interface (optional parts) to the back of
the set.
When you install the Monitor set using a wall mounting
interface (optional parts), attach it carefully so it will not
drop.
1 If you use screw longer than standard, the monitor
might be damaged internally.
2 If you use improper screw, the product might be dam-
aged and drop from mounted position.
In this case, LG Electronics is not responsible for it.
y
Disconnect the power cord first, and then
move or install the Monitor set. Otherwise
electric shock may occur.
y
If you install the Monitor set on a ceiling or
slanted wall, it may fall and result in severe
injury.
y
Use only an authorized LG wall mount
and contact the local dealer or qualified
personnel.
y
Do not over tighten the screws as this may
cause damage to the Monitor set and void
your warranty.
y
Use only screws and wall mounts that
meet the VESA standard. Any damages
or injuries by misuse or using an improper
accessory are not covered by the warranty.
y
Screw length from outer surface of back
cover should be under 8mm.
y
Use the screws that are listed on the VESA
standard screw specifications.
y
The wall mount kit will include an installation
manual and necessary parts.
y
The wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
y
The length of screws may differ depending
on the wall mount. Be sure to use the proper
length.
y
For more information, refer to the
instructions supplied with the wall mount.
CAUTION
NOTE
Back Cover
Wall mount Pad
Wall mount Pad
Back Cover
Standard screw
Max.8mm
y
Wall Mount (A x B)
A
B
Model
22MK4 series 24MK4 series
22BK4 series 24BK4 series
Wall Mount (A x B)
75 x 75
Standard screw
M4
Number of screws
4
Model
27MK4 series 27BK4 series
Wall Mount (A x B)
100 x 100
Standard screw
M4
Number of screws
4
100 mm
(3.94 inches)
100 mm
(3.94 inches)
100 mm
(3.94 inches)
100 mm
(3.94 inches)

LG 27MK430H Specifications

General

3D	No
DDC/CI	Yes
Screen shape	Flat
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	56 - 75 Hz
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Market positioning	Home
VGA (D-Sub) ports quantity	0
Tilt angle range	-5 - 20 °
Cables included	AC
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	- W

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	469 mm
Weight (with stand)	4600 g
Depth (without stand)	44 mm
Width (without stand)	626 mm
Height (without stand)	375 mm
Weight (without stand)	4200 g
