- 29 -
EXPLODED VIEW PARTS LIST
LOCA. NO PART NO DESCRIPTIONS
105 4810V01503B Bracket, CRT 32FS2 AC05MA HIPS 51SF .
112 6335932003K CPT,ITC W76ERS270XV1 S 32INCH SUPER-SLIM -0.50G 4/3
120 EAB30828501 Speaker,Fullrange C163A01K1451. ND 15W 8OHM 86DB 110HZ 193 X 57 X 44.4 LUG
150 EAP30771201 Coil,Degaussing 13.3/102ohm AL 47/380Ts 0.70mm SQUARE 32INCH 3720mm ASSEMBLY
170 6868900001A Drawing,Assembly EARTH SPRING 32INCH 144T 32FS1D
300 30919E0029C Cover Assembly, 32FS4D-TE 30909E0022 AUSTRALIA
310 5020V01110B Button, CONTROL 29FS4 ABS, HF-380 6KEY 7227S00117A”
320 320-062E Spring, CUTTING STSC304 KNOB
330 5020V01111B Button, POWER 29FS4 ABS, HF-380 1KEY 7227S00117A
331 4810V01272A Bracket, MOLD ABS CONTROL 32FS2D AC05MA ABS, HF-380
400 3809900135C Cover Assembly, 32FS4D-TE AUSTRALIA
501 4810V01239A Bracket, MOLD HIPS BOARD 32FS2D AC05MA HIPS 40AF .
503 4811V00359Q Bracket Assembly, REAR AV 32FS4D-TE CD61A AUSTRALIA
510 6871VSMZZ4C PCB Assembly,Sub CPT M.I AC05MA 32FS2D-NA AKRLLA CPT
520 68719MMW16A PCB Assembly,Main MAIN1 M.I AC05MA 32FS4D-TE .. MAIN1 1002A
530 68719SM067A PCB Assembly,Sub SUB M.I AC05MA 32FS2D AKRLLAK CONTROL
540 68719SMM34A PCB Assembly,Sub SUB M.I CD61A 32FS4D-TE AAULLAX POWER S/W AUSTRALIA
550 68719SM122B PCB Assembly,Sub SUB M.I AC05MA 32FS4D-AUS AUS HRS/CS
560 68719SM299A PCB Assembly,Sub SUB M.I AC05MA 32FS4D-TA AKRLLA AUS DIGITAL NEC
580 68719DM005B PCB Assembly,Deflection M.I AC05MA DEFLECTION 32FS4D TE AUS
590 68719SM068B PCB Assembly,Sub SUB M.I AC05MA 32FS4D AKRLLAK LED/PRE AMP
600 68719SM121B PCB Assembly,Sub SUB M.I AC05MA 32FS4D-NB AKRLLA SIDE A/V
913 FAB30021506 Screw Assembly, FAB30021506 TAPTITE P TYPE D7.0 L45.0 RUBBER(D20, T3.2)
943 FAB30006309 Screw,Taptite 1SZZ9PB012A TH + P 4MM 16MM MSWR10 FZB
P1802 6410VHH002E Power Cord Assembly, KJP-170F BL102RN 2.2M 200MM 250V 3A H03VVH2-F 2X0.75MM2
The components identified by mark is
critical for safety.
Replace only with part number specified.
To Next Page
