EXTERNAL EQUIPMENT SETUP
46
EXTERNAL EQUIPMENT SETUP
Composite (RCA) Connection
HDMI Connection
Connect the HDMI output of the DVD to the
HHDDMMII//DDVVII IINN
*,
HHDDMMII//DDVVII IINN 11
*,
HHDDMMII//DDVVII IINN
11((DDVVII))
*,
HHDDMMII 22
* or
HHDDMMII IINN 22
*/
33
* jack on the TV.
No separated audio connection is necessary.
HDMI supports both audio and video.
1. How to connect
2. How to use
■
Select the
HHDDMMII
*or
HHDDMMII11
*/
22
*/
33
* input source on
the TV using the
IINNPPUUTT
button on the remote control.
■
Refer to the DVD player's manual for operating instruc-
tions.
2
1
VID
HDMI
/DVI IN
HDMI
/DVI IN
HDMI HDMI
RS-232C IN
(CONTROL)
RGB IN (PC)
U
SERV
COMPONENT IN
AUDIOAUDIO
VIDEOVIDEO
11
22
HDMI OUTPUT
1
GG
Check HDMI cable over version 1.3.
If the HDMI cables don’t support HDMI
version 1.3, it can cause flickers or no
screen display. In this case use the latest
cables that support HDMI version 1.3.
GG
HDMI mode supports PCM audio format only.
GG
If the Audio setting is set to
Dolby/DTS/Bitstream in some DVDP/STB,
make sure to change the setting to PCM.
NOTE
!
L R
VIDEO
AUDIO
RS-232C IN
(CONTROL)
RGB IN (PC)
USB IN
SERVICE ONLY
AUDIO IN
(RGB/DVI)
ANTENNA
IN
AVAV
NENT IN
AUDIOAUDIO
L(MONO)L(MONO)
VIDEOVIDEO
ININ
RR
AUDIOAUDIO
VARIABLE AUDIO OUTVARIABLE AUDIO OUT
OUT
Connect the
AAUUDDIIOO
/
VVIIDDEEOO
jacks between TV and
DVD. Match the jack colors (Video = yellow, Audio Left
= white, and Audio Right = red).
1. How to connect
2. How to use
■
Turn on the DVD player, insert a DVD.
■
Select the
AA VV
* or
AAVV11
*/
22
* input source on the TV using
the
IINNPPUUTT
button on the remote control.
■
Refer to the DVD player's manual for operating instructions.
1
1
*
AA VV
: For 19/22/26/32/37/42LH20R, 19LU50R, 22LU50FR,
22LU40R, 42/47SL90QR, 22LD330
*
AAVV11
/
22
: For 32/42LF20FR, 32/37/42/47LH30FR, 26LU50FR,
42/47/55LH50YR, 32/42/47LH70YR, 42/47LH90QR,
32/42/47/55SL80YR, 26/32LD330, 32/42LD410, 32/42LD420,
32LD340, 26/32LD331C
*
HHDDMMII//DDVVII IINN
: For 19/22LH20R, 22LU40R, 22LD330
*
HHDDMMII//DDVVII IINN 11,, 22::
For 26/32LD330, 32LD340, 26/32LD331C
*
HHDDMMII//DDVVII IINN 11
,
HHDDMMII ((IINN)) 22
: For 26/32/37/42LH20R, 32/37/42/47LH30FR, 19LU50R,
22/26LU50FR, 32/42LF20FR, 32/42LD410
*
HHDDMMII IINN 33
: For 32/37/42/47LH30FR, 26LU50FR,32/42LD410, 32LD420
*
HHDDMMII//DDVVII IINN 11((DDVVII))
,
HHDDMMII IINN 22
/
33
: For 42/47/55LH50YR, 32/42/47LH70YR, 42/47LH90QR,
32/42/47/55SL80YR, 42/47SL90QR, 32/42LD420
*
HHDDMMII
: For 19/22LH20R, 22LU40R, 22LD330
*
HHDDMMII11
/
22
: Except 19/22LH20R, 22LD330
*
HHDDMMII33
: For 32/37/42/47LH30FR, 26LU50FR,
42/47/55LH50YR, 32/42/47LH70YR,
42/47LH90QR, 32/42/47/55SL80YR,
42/47SL90QR, 32/42LD410, 32/42LD420
MFL58486305-Edit1-en- 5/28/10 2:32 PM Page 46
