Interconnection - 4
[PCBs]
[Cables]
26LV5500
LCD Module
2
1
1
2
3
4
LED driver
1
Main PCB
2
Soft Touch Key/IR PCB
1
2
3
4
Soft Touch key/IR cable
Main / Module LVDS cable
LED driver / Module cable
SPK cable
