LG 32LM6370PLA User Manual

18
󱂅 Specifications
(Depending on country)
Broadcasting Specifications
Digital TV Analogue TV
Television system
DVB-S/S2
DVB-C
DVB-T/T2
PAL B/B, B/G, D/K, I,
SECAM B/G, D/K, L
Channel coverage
(Band)
DVB-S/S2 DVB-C DVB-T/T2
46 ~ 862 MHz
950 ~ 2,150 MHz 46 ~ 890MHz
VHF III : 174 ~ 230 MHz
UHF IV : 470 ~ 606 MHz
UHF V : 606 ~ 862 MHz
S Band II : 230 ~ 300 MHz
S Band III : 300 ~ 470 MHz
Maximum number of
storable programmes
6,000 3,000
External antenna
impedance
75Ω
CI Module (W x H x D) 100.0mm x 55.0mm x 5.0mm
Wireless module (LGSBWAC92) specifications
Wireless LAN (IEEE 802.11a/b/g/n/ac)
Frequency range Output Power (Max.)
2,400 to 2,483.5MHz 18dBm
5,150 to 5,725MHz 18dBm
5,725 to 5,850MHz (Not for EU) 12dBm
Bluetooth
Frequency range Output Power (Max.)
2,400 to 2,483.5MHz 8dBm
As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional
frequency table.
For consideration of the user, this device should be installed and operated with a minimum distance of 20 cm between the device and the body.
* IEEE 802.11ac is not available in all countries.
Environment condition
Operating Temperature 0°C to 40°C
Operating Humidity Less than 80%
Storage Temperature -20°C to 60°C
Storage Humidity Less than 85%
• For information of the power supply and power consumption, refer to the label attached to the product.
- The typical power consumption is measured in accordance with IEC 62087 or each country’s energy regulations.
* On some models, the label is inside the external device connection terminal cover.
* Depending on the model or country, the typical power consumption may not be on label.

LG 32LM6370PLA Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	32 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	-
Display diagonal (metric)	81.28 cm
AMD FreeSync	No
Processor cores	4
Video formats supported	HEVC, VP9
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Tuner type	Digital
Digital signal format system	DVB-S2, DVB-T2
Video apps	Catch-up TV, Chili, Mediaset Play, RaiPlay
Operating system version	4.5
Operating system installed	Web OS
Audio decoders	DTS, Dolby Digital
RMS rated power	10 W
Number of speakers	2
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Color name	Smokey White
Product color	Black
Panel mounting interface	200 x 200 mm
Quantity per pack	1 pc(s)
Annual energy consumption	50 kWh
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	36 W
Certification	Tivùon! / Tivùsat, Lativù, HbbTV v 2.0.1, CAMREADY
Package depth	142 mm
Package width	812 mm
Package height	510 mm
Package weight	5850 g

Weight and Dimensions

Depth (with stand)	180 mm
Width (with stand)	736 mm
Height (with stand)	464 mm
Weight (with stand)	4700 g
Depth (without stand)	82.9 mm
Height (without stand)	437 mm
Weight (without stand)	4650 g
