LG 32SM5KD User Manual

ENGLISH
73
64. [Scan Inversion] (Command: s n, 87)
Turns on/off Scan Inversion.
Transmission
(s)(n)( )([Set ID])( )(8)(7)( )(Data)(Cr)
Data 00: [Off]
01: [On]
Acknowledgment
(n)( )([Set ID])( )(OK/NG)(8)(7)(Data)(x)
* This feature may not be supported on some models.
* Video wall models require to be rebooted for the normal
operation after the values are changed.
65. [Beacon] (Command: s n, 88)
Turns on/off Beacon.
Transmission
(s)(n)( )([Set ID])( )(8)(8)( )(Data)(Cr)
Data 00: [Off]
01: [On]
Acknowledgment
(n)( )([Set ID])( )(OK/NG)(8)(8)(Data)(x)
* This feature may not be supported on some models.
66. [Brightness Scheduling] Mode (Command: s m)
Selects a Brightness Scheduling mode.
Transmission
(s)(m)( )([Set ID])( )(Data)(Cr)
Data 00: Brightness Scheduling off
01: Brightness Scheduling on
* This feature does not work if the current time is not set.
* This feature may not be supported on some models.
Acknowledgment
(m)( )([Set ID])( )(OK/NG)(Data)(x)
67. [Brightness Scheduling] (Command: s s)
Sets Brightness Scheduling.
Transmission
(s)(s)( )([Set ID])( )(Data1)( )(Data2)( )(Data3)(Cr)
Data1
1. f1 to f6 (data reading)
F1: Reads the 1st brightness schedule's data
F2: Reads the 2nd brightness schedule's data.
F3: Reads the 3rd brightness schedule's data.
F4: Reads the 4th brightness schedule's data.
F5: Reads the 5th brightness schedule's data.
F6: Reads the 6th brightness schedule's data.
FF: Reads all stored lists
3. e1 to e6 (Deletes one index), e0 (Deletes all indexes)
E0: Deletes all brightness schedules.
E1: Deletes the 1st brightness schedule.
E2: Deletes the 2nd brightness schedule.
E3: Deletes the 3rd brightness schedule.
E4: Deletes the 4th brightness schedule.
E5: Deletes the 5th brightness schedule.
E6: Deletes the 6th brightness schedule.
4. 00 to 17: Hour 00 to hour 23
Data2 00 to 3B: Minute 00 to minute 59th
Data2 00 to 64: Backlights 0 to 100
* To read or delete a brightness schedule you have set, [Data2]
[Data3] must be set to FF.
* If you want to read all configured brightness schedules
through FF, do not enter any values in [Data2][Data3].
* When all configured brightness schedules are read through
FF, OK is acknowledged even if there is no stored list.
Example 1: fd 01 f1 ff ff - Reads the 1st index data in
Brightness Scheduling.
ex2: sn 01 1b ff ff ff ff – Reads all index data in in Brightness
Scheduling.
Example 3: fd 01 e1 ff ff - Deletes the 1st index data in
Brightness Scheduling.
Example 4: ss 01 07 1E 46 - Adds a schedule whose time is
07:30 and whose backlight is 70.
* This feature may not be supported on some models.
Acknowledgment
(s)( )([Set ID])( )(OK/NG)(Data1)(Data2)(Data3)(x)
