155
APPENDIX
0088.. CCoolloouurr ((CCoommmmaanndd:: kk ii))
G To adjust the screen colour.
You can also adjust colour in the PICTURE menu.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping 1’. See page 157.
[k][i][ ][Set ID][ ][Data][Cr]
Ack
[i][ ][Set ID][ ][OK/NG][Data][x]
0044.. VVoolluummee MMuuttee ((CCoommmmaanndd:: kk ee ))
G To control volume mute on/off.
You can also adjust mute using the MUTE button on
remote control.
Transmission
Data 00 : Volume mute on (Volume off)
01 : Volume mute off (Volume on)
[k][e][ ][Set ID][ ][Data][Cr]
Ack
[e][ ][Set ID][ ][OK/NG][Data][x]
0022.. AAssppeecctt RRaattiioo ((
CCoommmmaanndd:: kk
cc)) ((MMaaiinn PPiiccttuurree SSiizzee))
G To adjust the screen format. (Main picture format)
You can also adjust the screen format using the
AAssppeecctt RRaattiioo
in the Q.MENU. or PICTURE menu.
Transmission
Data 01 : Normal screen (4:3)
02 : Wide screen (16:9)
04 : Zoom
06 : Original
07 : 14:9
09 : Just Scan
0B : Full Wide
10 ~1F : Cinema Zom 1~16
[k][c][ ][Set ID][ ][Data][Cr]
Ack
* Using the PC input, you select either 16:9 or 4:3
screen aspect ratio.
*
In DTV/HDMI (1080i 50Hz/60Hz, 720p 50Hz/60Hz,
1080p 24Hz/30Hz/50Hz/60Hz), Component( 720p,
1080i, 1080p 50Hz/60Hz) mode, Just Scan is avail-
able.
*
FFuullll WWiiddee
is supported only for
Analogue
, AV1,2,3.
[c][ ][Set ID][ ][OK/NG][Data][x]
0033.. SSccrreeeenn MMuuttee ((CCoommmmaanndd:: kk dd ))
G To select screen mute on/off.
Transmission
Data 00 : Screen mute off (Picture on)
Video mute off
01 : Screen mute on (Picture off)
10 : Video mute on
* In case of video mute on only, TV will display On Screen
Display(OSD). But, in case of Screen mute on, TV will not
display OSD.
[k][d][ ][Set ID][ ][Data][Cr]
Ack
[d][ ][Set ID][ ][OK/NG][Data][x]
0055.. VVoolluummee CCoonnttrrooll ((CCoommmmaanndd:: kk ff ))
G To adjust volume.
You can also adjust volume with the VOLUME buttons on
remote control.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping 1’. See page 157.
[k][f][ ][Set ID][ ][Data][Cr]
Ack
[f][ ][Set ID][ ][OK/NG][Data][x]
0066.. CCoonnttrraasstt ((CCoommmmaanndd:: kk gg ))
G To adjust screen contrast.
You can also adjust contrast in the PICTURE menu.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping 1’. See page 157.
[k][g][ ][Set ID][ ][Data][Cr]
Ack
[g][ ][Set ID][ ][OK/NG][Data][x]
0077.. BBrriigghhttnneessss ((CCoommmmaanndd:: kk hh ))
G To adjust screen brightness.
You can also adjust brightness in the PICTURE menu.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping 1’ See page 157.
[k][h][ ][Set ID][ ][Data][Cr]
Ack
[h][ ][Set ID][ ][OK/NG][Data][x]
0011.. PPoowweerr ((CCoommmmaanndd:: kk aa))
G To control Power On/Off of the set.
Transmission
Data 00 : Power Off 01 : Power On
[k][a][ ][Set ID][ ][Data][Cr]
Ack
[a][ ][Set ID][ ][OK/NG][Data][x]
G To show Power On/Off.
Transmission
[k][a][ ][Set ID][ ][FF][Cr]
Ack
* Similarly, if other functions transmit ‘0xFF’ data based
on this format, Acknowledgement data feed back pre-
sents status about each function.
* OK Ack., Error Ack. and other message may display on
the screen when TV is power On.
[a][ ][Set ID][ ][OK/NG][Data][x]
