24
ENG
ENGLISH
MAKING CONNECTIONS
Satellite dish Connection
(Only satellite models)
Connect the TV to a satellite dish to a satellite
socket with a satellite RF cable (75 Ω).
LNB
Satellite IN
13/18V
700mA Max
Satellite
Dish
HDMI Connection
Transmits the digital video and audio signals from
an external device to the TV. Connect the external
device and the TV with the HDMI cable as shown.
NOTE
It is recommended to use the TV with the
HDMI connection for the best image quality.
Use the latest High Speed HDMI™ Cable
with CEC (Customer Electronics Control)
function.
High Speed HDMI™ Cables are tested to
carry an HD signal up to 1080p and higher.
Supported HDMI Audio format : Dolby
Digital, PCM (Up to 192 KHz, 32 KHz / 44.1
KHz / 48 KHz / 88 KHz / 96 KHz / 176 KHz /
192 KHz)
- DTS Not supported.
If you use DVI to HDMI cable for PC, you
have to use external speaker for PC audio
sound.
DVD / Blu-Ray /
HD Cable Box / HD STB / PC
To Next Page
