- 31 -

Only for training and service purposes

120 EAB30829201 Speaker, Woofer g1560102 ND 15W 8OHM 82DB 100HZ 193 X 57 X 50 LUG MACOM

200 EAJ38199501 PDP, Module-XGA PDP42X40523.ASLGB XGA 42INCH 1024X768 16/9 PDP DIVISION

201 EBR36954101 Hand Insert PCB Assembly, CTRL ASS’Y HAND INSERT 42” X4A CTRL PDP DIVISION

202 EBR36939101 Hand Insert PCB Assembly, YDRV ASS’Y HAND INSERT 42” X4A AU Layer 4 PDP DIVISION

203 EBR36925801 Hand Insert PCB Assembly, XRLT ASS’Y HAND INSERT 42” X4A Layer 4 PDP DIVISION

204 EBR36939201 Hand Insert PCB Assembly, XRRT ASS’Y HAND INSERT 42” X4A PDP DIVISION

205 EBR36954501 Hand Insert PCB Assembly, YSUS ASS’Y HAND INSERT 42” X4A YSUS PDP DIVISION

206 EBR36921701 Hand Insert PCB Assembly, ZSUS ASS’Y HAND INSERT 42” X4A 2 Layer (OSP) PDP DIVISION

240 4980900366C Supporter, CASTING ALDC NON AL NON

250 4980900366D Supporter, CASTING ALDC NON AL NON

300 30919E0076D Cover Assembly, 42PC35-ZC.KEUYLMP PD74A 42” LGEMA B/K SPRAY APPLY

301 4980900367A Supporter, ASSY AL FILTER TOP,42PC1,LGEMA

302 4980900368A Supporter, ASSY AL FILTER BOTT, 42PC1,LGEMA

303 4980900369A Supporter, ASSY AL ASSY AL FILTER RIGHT, 42PC1,LGEMA

304 4980900370B Supporter, PRESS AL 0.8 Supporter AL FILTER 42PC35-ZC APPLY (GASKET 3t)

400 MCK30275905 Cover, PRESS PCM 0.4 42PC35-ZC AL WITHOUT HANDLE 42PC3 ANALOG TYPE

501 AGU30208005 Plate Assembly, ASSY AV PLATE 42PC35-ZC EUROPASS3 CHASSIS APPLY

502 AGU34705202 Plate Assembly, REAR AV PLATE COVER ASSEMBLE 42PC35 & 50PC35 EU EUROPASS3 BASIC PRESS

520 EBR39660222 Hand Insert PCB Assembly, Main MAIN M.I PD73A 42PC35-ZC KEKLLMP Hand Insert PCB Assembly MAIN for MA_CKD

560 68719SML76A Hand Insert PCB Assembly, Sub SUB M.I PD61A 42PC3D-EC . -

570 EBR40151401 PCB Assembly, Sub SUB T.T PD73A 42PC35-ZC KEKLLMP SUB IR PCB Package Assembly for MA CKD

580 EAY32808901 SMPS, AC/DC YPSUJ014A 100VTO240V 400W 50 TO 60HZ UL/CSA/CE/TUV 42INCH XPOWER DISPLAY PSU LG

590 6200J000115 Filter, AC Line IJ-N06CESL1 5.3mH 250VAC 6A 0.22uF 1000pF UL/VDE/CSA/TUV/CCC HOUSING/RING BK DONGJI

600 EBR39741801 Hand Insert PCB Assembly, Sub SUB M.I PD73A 42PC35 AEULLHX Hand Insert PCB Assembly SUB Side AV

601 4811900021M Bracket Assembly, SIDE AV 42PC35 & 50PC35-ZC PD74A EUROPASS3

602 48149V0003A Plate, PRESS SPTE T0.3 SIDE AV 42PC1R

900 3501900014R Base Assembly, STAND AP-42DC11 PN61A FOLDING STAND LGEMA LOCAL ASSEMBLE PHANTOM (B/K COSMETIC)

A2 AKB33871401 Remote Controller Assembly, 19_22LS4D, EU(PAL), LD73B

A21 MCK36759201 Cover, MOLD ABS HF-380 MKJ339814 ABS, HF-380 TX BATTERY COVER

EXPLODED VIEW PARTS LIST

No. Part No. Descriptions

The components identified by mark is

critical for safety.

Replace only with part number specified.
