12
PREPARATION
Stand Instructions
r Image shown may differ from your TV.
INSTALLATION DETACHMENT
Carefully place the TV screen side
down on a cushioned surface to
protect the screen from damage.
Carefully place the TV screen side
down on a cushioned surface to
protect the screen from damage and
remove the screws.
Connect the base to the stand and
install the 8 screws into the holes as
shown.
Detach the stand from the TV.
1 1
2 2
NOTE
a When assembling the desk type stand, make sure the screws are fully tightened
(If not tightened fully, the TV can tilt forward after the product installation). Do
not over tighten.
(M4 x 8)
*Use the safety screw
to secure the stand
on the table
To Next Page
