7
ENGLISH
• Make sure that children do not climb on or
hang on the TV.
• Use a platform or cabinet that is strong and
large enough to support the TV securely.
• Brackets, bolts, and ropes are optional. You
can obtain additional accessories from your
local dealer.
Mounting on a Wall
An optional wall mount can be used with your
LG Television. Consult with your local dealer for
a wall mount that supports the VESA standard
used by your TV model. Carefully attach the wall
mount bracket at the rear of the TV. Install the wall
mount bracket on a solid wall perpendicular to the
floor. If you are attaching the TV to other building
materials, please contact qualified personnel to
install the wall mount. Detailed instructions will
be included with the wall mount. We recommend
that you use an LG brand wall mount. The LG wall
mount is easy to adjust or to connect the cables.
When you do not use LG’s wall mount bracket,
use a wall mount bracket where the device is
adequately secured to the wall with enough space
to allow connectivity to external devices. If you are
using a non-adjustable mount, attach the mount
to the wall. Attach the cables to the TV first, then
attach the TV to the mount.
10 cm
10 cm
10 cm
10 cm
(4 inches)
Make sure to use screws and wall mounts that
meet the VESA standard. Standard dimensions for
the wall mount kits are described in the following
table.
Model 43UJ6500
43UJ6560
49UJ6500
49UJ6560
55UJ6540
55UJ6520
55UJ6580
VESA (A x B) 200 x 200 300 x 300
Standard screw M6 M6
Number of
screws
4 4
Wall mount
bracket
(optional)
LSW240B
MSW240
LSW350B
MSW240
Model 60UJ6540
65UJ6540
65UJ6520
65UJ6580
70UJ6570
70UJ657A
70UJ6520
75UJ6470
75UJ657A
75UJ6520
75UJ6450
VESA (A x B) 300 x 300 600 x 400
Standard screw M6 M8
Number of
screws
4 4
Wall mount
bracket
(optional)
LSW350B LSW640B
A
B
• Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
