- 31 -
LGE Internal Use OnlyCopyright©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
101 5900904001A Fan Module, 1.7KRPM DC 12V 250UA 3W 50HZ 1.5M3 per MIN 396X60.2X108.3MM DONGYANG CHEMICAL
120 EAB33775101 Speaker, Full Range EN1562C-6712 ND 10W 8OHM 82DB 100HZ 193.5 X 42 X 39.9 LUG KOREA TOPTONE
200 EAJ38568401 PDP, Module-XGA PDP50X40B36.ASLGB XGA 50INCH 1365X768 16/9 PDP DIVISION
201 EBR35959201 Hand Insert PCB Assembly, CTRL ASS’Y HAND INSERT 50” X4A 4006W & 256CH CTRL PDP DIVISION
202 EBR37397801 Hand Insert PCB Assembly, YDRV ASS’Y HAND INSERT 50” X4A Reduce Size. (6.5mm) AU. YDRVT PDP DIVISION
203 EBR37398001 Hand Insert PCB Assembly, YDRV ASS’Y HAND INSERT 50” X4A Reduce Size (6.5mm). AU. YDRVB PDP DIVISION
204 EBR35855501 Hand Insert PCB Assembly, XRLT ASS’Y HAND INSERT 50” X4A 256CH PDP DIVISION
205 EBR35856701 Hand Insert PCB Assembly, XRCT ASS’Y HAND INSERT 50” X4A 256CH PDP DIVISION
206 EBR35856201 Hand Insert PCB Assembly, XRRT ASS’Y HAND INSERT 50” X4A 256CH PDP DIVISION
207 EBR37284101 Hand Insert PCB Assembly, YSUS ASS’Y HAND INSERT 50” X4A Change ER Coil. 2L. OSP PDP DIVISION
208 EBR37284601 Hand Insert PCB Assembly, ZSUS ASS’Y HAND INSERT 50” X4A Change ER Coil. 2L. OSP PDP DIVISION
240 AJJ31591603 Supporter Assembly, 50PC5 SUPPORTER VERTICAL RIGHT FOR SKD
250 AJJ31591604 Supporter Assembly, 50PC5 SUPPORTER VERTICAL LEFT FOR SKD
300 ABJ31591212 Cabinet Assembly, 50PC5D-ZB NON 50” 50PC5R-ZB,50PC5D-ZB LEMEA LOCAL PHANTOM
301 AJJ31592505 Supporter Assembly, 50PC5 SUPPORTER TOP ASSY FOR PHANTOM,LGEMA ASSY
302 AJJ31592605 Supporter Assembly, 50PC5 SUPPORTER BOTTOM ASSY FOR PHANTOM,LGEMA ASSY
303 AJJ31592705 Supporter Assembly, 50PC5 SUPPORTER RIGHT ASSY FOR PHANTOM,LGEMA ASSY
304 AJJ31592805 Supporter Assembly, 50PC5 SUPPORTER LEFT ASSY FOR PHANTOM,LGEMA ASSY
306 ABA31592903 Bracket Assembly, DECO 50PC51-ZB,50PC55-ZB NON DECO BRACKET ASSY (Direct Grill) LGEMA 2ton
400 ACQ31591305 Cover Assembly, 50PC5R-ZB NON 50” PCM SECD 0.5t FOR LGEMA local
501 AGU31681116 Plate Assembly, ASSY PLATE TUNER BOT SMALL, 42PC5D-ZB ,MA LOCAL
502 AGU31680922 Plate Assembly, ASSY 42PC5D-ZB(WITH SLOT CARD, MA LOCAL)
520 EBR34792221 Hand Insert PCB Assembly, Main MAIN M.I PD73A 50PC5D KEKLLMP Main M.I PCB Ass’y 50PC5D-ZB for MA_CKD
560 EBR33718501 Hand Insert PCB Assembly, Sub SUB M.I PD73A 42PC5D - 42PC5D CONTROL MANUAL(Hand Insert PCB)
570 EBR33721001 Hand Insert PCB Assembly, Sub SUB M.I PD73A 42PC5D - 42PC5D IR/LED
580 EAY32957901 SMPS, AC/DC YPSU-J017A 100VTO240V 530W 50 TO 60HZ UL/CE/TUV 50INCH PDP XPOWER LGIT PSU YPSU-J017A
590 EAM35012703 Filter, AC Line IF2-N06CEWL2 5.3mH 250VAC 6A 0.22uF 1000pF VDE/CSA/K/CCC 450/130MM CORE ADDTION
600 EBR33717101 Hand Insert PCB Assembly, Sub SUB M.I PD73A 42PC5D - 42PC5D side AV hand insert PCB Assy
601 MJH32554904 Supporter, PRESS SBHG 1 GUIDE EGI SUPPORTER SIDE, 42X4A MODULE
602 MGJ32369301 Plate, Shield PRESS SPTE 0.3 SHIELD SPTE 42PC5, SHIELD CASE SIDE AV
603 ABA31583301 Bracket Assembly, SIDE AV 42PC5 AB NON
900 AAN31593104 Base Assembly, STAND 50PC5 NON 50PC5 FIX STAND FOR “PLASMA DISPLAY PANEL” SKD
901 MCK32604801 Cover, MOLD ABS 42PC5 ABS CABLE MANAGEMENT
A2 MKJ39170804 Remote Controller, COMPLEX LD73A 26LC4 EUROPASS_DVB, Made in China, MKJ32022813
A21 3550V00590A Cover, MOLD ABS 50PC3DD-UE.AUSRSHR ABS -
EXPLODED VIEW PARTS LIST
No. Part No. Descriptions
The components identified by mark is
critical for safety.
Replace only with part number specified.
To Next Page
