- 32 -

Only for training and service purposes

C1 0CK104DK56A 0805B104K500CT 100nF 10% 50V X7R

C100 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V C0G

C100 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V C0G

C100 0CC470CK41A C1608C0G1H470JT 47pF 5% 50V C0G -

C1003 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -

C1004 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -

C1005 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -

C1006 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -

C1007 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1008 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1009 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C101 0CE4763F618 ESF476M016T1A5E05G 47uF 20% 16V 6

C101 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V C0G

C101 0CK103BH56A C1005X7R1E103KT- 10nF 10% 25V X7R

C1010 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C102 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V 16MA

C102 0CE4763F618 ESF476M016T1A5E05G 47uF 20% 16V 6

C103 0CE4763F618 ESF476M016T1A5E05G 47uF 20% 16V 6

C103 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C104 0CH5330K416 C2012C0G1H330JT 33pF 5% 50V C0G -

C104 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V X7R -

C105 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C106 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1068 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 16V 11

C107 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C108 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C109 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V X7R -

C110 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V 16MA

C1100 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C1100 0CC100CK41A C1608C0G1H100JT 10pF 5% 50V C0G -

C1101 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C1101 0CC100CK41A C1608C0G1H100JT 10pF 5% 50V C0G -

C1104 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -

C1105 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -

C1106 0CC120CK41A C1608C0G1H120JT 12pF 5% 50V C0G -

C1108 0CC120CK41A C1608C0G1H120JT 12pF 5% 50V C0G -

C111 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1116 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1119 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C112 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1120 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1121 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1123 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1125 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1128 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C113 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1132 0CC681CK41A C1608C0G1H681JT 680pF 5% 50V C0G

C1133 0CK104BF56A C1005X7R104KET 100nF 10% 16V X7R

C1134 0CK104BF56A C1005X7R104KET 100nF 10% 16V X7R

C1135 0CK225DFK4A C2012Y5V1C225MT 2.2uF 20% 16V Y5V

C1135 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1136 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C114 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C115 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C116 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C117 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C118 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V 16MA

C119 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C120 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1205 0CK393CK56A 0603B393K500CT 39nF 10% 50V X7R -

C1206 0CK102CK56A 0603B102K500CT 1nF 10% 50V X7R -5

C1207 0CK393CK56A 0603B393K500CT 39nF 10% 50V X7R -

C1208 0CK102CK56A 0603B102K500CT 1nF 10% 50V X7R -5

C121 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1217 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V 25MA

C122 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1225 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V 25MA

C123 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1232 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 16V 11

C1234 0CK102CK56A 0603B102K500CT 1nF 10% 50V X7R -5

C1235 0CK102CK56A 0603B102K500CT 1nF 10% 50V X7R -5

C1236 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V 25MA

C1237 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V 25MA

C1239 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C124 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1244 0CK393CK56A 0603B393K500CT 39nF 10% 50V X7R -

C1246 0CK393CK56A 0603B393K500CT 39nF 10% 50V X7R -

C1247 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 16V 11

C1248 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C1249 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C125 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1250 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C1251 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C1252 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C1253 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C1254 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C1255 0CC050CK11A C1608C0G1H050DT 5pF 0.5PF 50V C0G

C126 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C127 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C128 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C129 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C130 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R

C1300 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X7R -5

C1301 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1302 0CE108EH618 KMG5.0TP25VB1000M 1000uF 20% 25V

C1303 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X7R -5

C1304 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1305 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R

C1306 0CK222CK56A 0603B222K500CT 2.2nF 10% 50V X7R

LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION

REPLACEMENT PARTS LIST

DATE: 2007. 09. 01.

CAPACITORs
